Extruded 97% Alumina Based Ceramics Tubing For Electronic Manufacturing OEM
Extruded 97% Alumina Based Ceramics Tubing For Electronic Manufacturing OEM
Extruded 97% Alumina Based Ceramics Tubing For Electronic Manufacturing OEM
Extruded 97% Alumina Based Ceramics Tubing For Electronic Manufacturing OEM
Extruded 97% Alumina Based Ceramics Tubing For Electronic Manufacturing OEM
Extruded 97% Alumina Based Ceramics Tubing For Electronic Manufacturing OEM
Extruded 97% Alumina Based Ceramics Tubing For Electronic Manufacturing OEM
Extruded 97% Alumina Based Ceramics Tubing For Electronic Manufacturing OEM
Specifications
Brand Name :
HENGYUAN
Model Number :
95% Alumina Ceramics
Certification :
CE,UL
Place of Origin :
WUXI JIANGSU CHINA
MOQ :
100
Price :
$1-$20
Payment Terms :
L/C, T/T
Supply Ability :
5000 PCS/WEEK
Delivery Time :
20 DAYS
Packaging Details :
Carton
Material :
95% Alumina Ceramics
Color :
White
Weibull Modulus :
10M
Density :
3.6 g/cm³
OEM，ODM :
Acceptable
Orgin :
WUXI JIANGSU CHINA
MOQ :
100 PCS
Package :
Carton
Description
High Performance 95% Alumina Ceramics Components For Electronic Manufacturing
Product Specifications
Material
95% Alumina Ceramics
Color
White
Weibull Modulus
10M
Density
3.6 g/cm³
OEM/ODM
Acceptable
Origin
Wuxi Jiangsu, China
MOQ
100 PCS
Package
Carton
Product Description
Our alumina ceramic series are classified by Al₂O₃ content into 95%, 97%, 99%, and 99.7% varieties. Higher alumina content enhances material properties but increases manufacturing complexity. The 95% alumina ceramic offers an optimal balance of performance and cost-effectiveness for electronic manufacturing applications.
Technical Properties Comparison
Material Unit 95% Alumina 97% Alumina 99% Alumina 99.7% Alumina
Density g/cm³ 3.6 3.72 3.85 3.85
Flexural Strength Mpa 290 300 350 350
Compressive Strength Mpa 3300 3400 3600 3600
Modulus of Elasticity Gpa 340 350 380 380
Impact Resistance MPam1/2 3.9 4 5 5
Weibull Modulus M 10 10 11 11
Vickers Hardness HV0.5 1800 1850 1900 1900
Thermal Expansion Coefficient 10-6K-1 5.0-8.3 5.0-8.3 5.4-8.3 5.4-8.3
Thermal Conductivity W/Mk 23 24 27 27
Thermal Shock Resistance △T℃ 250 250 270 270
Maximum Use Temperature ℃ 1600 1600 1650 1650
Volume Resistivity at 20℃ Ω ≥1014 ≥1014 ≥1014 ≥1014
Dielectric Strength KV/mm 20 20 25 25
Dielectric Constant εr 10 10 10 10
Product Images
Extruded 97% Alumina Based Ceramics Tubing For Electronic Manufacturing OEM Extruded 97% Alumina Based Ceramics Tubing For Electronic Manufacturing OEM Extruded 97% Alumina Based Ceramics Tubing For Electronic Manufacturing OEM Extruded 97% Alumina Based Ceramics Tubing For Electronic Manufacturing OEM Extruded 97% Alumina Based Ceramics Tubing For Electronic Manufacturing OEM Extruded 97% Alumina Based Ceramics Tubing For Electronic Manufacturing OEM Extruded 97% Alumina Based Ceramics Tubing For Electronic Manufacturing OEM Extruded 97% Alumina Based Ceramics Tubing For Electronic Manufacturing OEM Extruded 97% Alumina Based Ceramics Tubing For Electronic Manufacturing OEM Extruded 97% Alumina Based Ceramics Tubing For Electronic Manufacturing OEM Extruded 97% Alumina Based Ceramics Tubing For Electronic Manufacturing OEM Extruded 97% Alumina Based Ceramics Tubing For Electronic Manufacturing OEM Extruded 97% Alumina Based Ceramics Tubing For Electronic Manufacturing OEM Extruded 97% Alumina Based Ceramics Tubing For Electronic Manufacturing OEM Extruded 97% Alumina Based Ceramics Tubing For Electronic Manufacturing OEM Extruded 97% Alumina Based Ceramics Tubing For Electronic Manufacturing OEM Extruded 97% Alumina Based Ceramics Tubing For Electronic Manufacturing OEM
