TXB Series Cam-type Rubber Lobe Pump for Wastewater Sludge Environmental Treatment
TXB Series Cam-type Rubber Lobe Pump for Wastewater Sludge Environmental Treatment
TXB Series Cam-type Rubber Lobe Pump for Wastewater Sludge Environmental Treatment
TXB Series Cam-type Rubber Lobe Pump for Wastewater Sludge Environmental Treatment
Specifications
Media Type :
Gas-liquid-solid three-phase
Certification :
ISO 9001:2015
Packaging Details :
Export wooden case packaging, seaworthy and moisture-proof
MOQ :
1 Set
Discharge Pressure :
≤1.2 MPa
Place of Origin :
Jiangsu, China
Application :
Sewage, sludge, slurry conveying
Model Number :
TXB
Price :
USD 1500-8000 / Set
Brand Name :
Juneng
Payment Terms :
T/T,L/C
Wetted Material :
Cast iron / NBR rubber
Flow Range :
2-100 m3/h
Supply Ability :
200 Sets per Month
Delivery Time :
15-30 days after order confirmation
Solid Particle Size :
up to 50 mm
Description
TXB Series Cam-type Rubber Lobe Pump for Wastewater Sludge Environmental Treatment
Product Overview

The TXB series cam-type rubber lobe pump (rotary lobe pump) is a self-priming positive displacement pump designed for conveying gas-liquid-solid three-phase mixed media and unstable, easily vaporized media. With strong self-priming capability, it is widely used in municipal sewage, sludge, chemical dosing, suspended solids, manure, fertilizer solution and oil spill collection.

Working Principle

Two synchronized cam-shaped rotors with rubber (elastomer) lobes rotate in opposite directions inside the pump casing. As the rotors rotate, the sealed chamber between the lobes and the casing periodically changes in volume, drawing the medium in on the inlet side and discharging it on the outlet side. The flexible rubber lobes provide excellent self-priming performance and allow the pump to convey gas-liquid-solid three-phase mixtures and media that are unstable or easily vaporized. Equipped with a frequency converter, the pump delivers precise metering and supports reversible (bidirectional) operation.

Key Features
  • Strong self-priming ability, ideal for gas-liquid-solid three-phase mixed media
  • Handles unstable gas-liquid and easily vaporized media reliably
  • Frequency converter metering with high precision and stable operation
  • Reversible bidirectional operation for flexible conveying processes
  • Rubber lobes provide gentle, low-shear and abrasion-resistant conveying
Technical Specifications (TXB Series)
Model Flow (m³/h) Pressure (MPa) Speed (r/min) Power (kW) Inlet/Outlet (mm)
TXB-5 2-5 ≤1.2 50-450 1.5-3 DN40
TXB-10 5-10 ≤1.2 50-400 3-5.5 DN50
TXB-20 10-20 ≤1.0 50-350 5.5-11 DN65
TXB-30 20-30 ≤1.0 50-300 11-15 DN80
TXB-50 30-50 ≤0.8 50-250 15-22 DN100
TXB-80 50-80 ≤0.8 50-250 22-30 DN125
TXB-100 80-100 ≤0.6 50-200 30-37 DN150
Applications
  • Environmental protection: municipal sewage, sludge, chemical dosing, suspended solids, manure, fertilizer solution, oil spill collection
  • Paper making: calcium carbonate, pulp, filler, coating, papermaking wastewater
  • Firefighting: firefighting liquid, firefighting water, water-surface oil spill suction
  • Others: mining slurry, lime slurry, gypsum mud, livestock manure conveying
Frequently Asked Questions
Q: What media is this pump best suited for?
A: It is ideal for gas-liquid-solid three-phase mixed media, unstable gas-liquid and easily vaporized media such as municipal sewage, sludge, suspended solids and slurry.
Q: Does it have self-priming ability?
A: Yes, it offers strong self-priming capability and can convey gas-liquid-solid three-phase mixed materials.
Q: Can it handle solid particles?
A: Yes, the flexible rubber lobes allow it to convey media containing solid particles up to 50 mm.
Q: Can it run in reverse?
A: Yes, it supports reversible bidirectional operation to meet different conveying process requirements.
Q: What is the minimum order quantity?
A: The minimum order quantity is 1 set. The full TXB series is available.
