Multi-Spectrum Small U-Turret Camera
Key Features
- The MCL-PT008 is a long range camera equipped with an observation-type thermal imaging lens,Laser and Rangefinder
- Spherical rotational structure allows for multi-angle observation with horizontal range of 0° to 360° and vertical range of -60° to +70°
Application Environment
Forest Fire Prevention
Army Border Guard
The Army Defends the Coast
Ships
Shipping Port
Unlike manual zoom lenses, electric zoom lenses are used in a wide range of outdoor scenes covering extensive focal lengths. The focal length can be adjusted remotely to zoom in on important areas, providing excellent monitoring capabilities. With continuous development in the security industry and increased infrastructure investment, demand for electric zoom lenses has grown significantly in urban security, highways, railways, forest fire prevention, maritime management, ports, border defense, and oil fields.
Main Features
| Material | Aluminum Alloy (with powder coating) |
| Protection Class | IP66 |
| Working Temperature | -40℃~+65℃ |
| Working Humidity | <90% |
| Video | IP |
| Visible Resolution | 2MP |
| Visible Focal Length | 30x optical zoom |
| Thermal Resolution | 640*512 |
| Thermal Length | 50mm |
| Laser Range | 500m |
| Rangefinder Range | 3000m |
| Bulid-in | 2D Eletronic Compass |
| Motor & Transmission Method | Torque Motor Direct Drive Method |
| Rotation Range | Horizontal: 0~360° (0.09°~120°/s) Vertical: -60°~+70° (0.09°~110°/s) |
| Function | Top-mounted Payload (Self-locking 5KG),Gyro Stabilization, Optical Fog Penetratior |
| Voltage | DC24V (≤50W) |
| Weight | ≤15kg |
| Mounting | Formal Installation, Four-Point Base Fixation |
