Semi Automatic Servo Feeding Overwrapper Machine Flat Seal Tray
Semi Automatic Servo Feeding Overwrapper Machine Flat Seal Tray
Semi Automatic Servo Feeding Overwrapper Machine Flat Seal Tray
Semi Automatic Servo Feeding Overwrapper Machine Flat Seal Tray
Semi Automatic Servo Feeding Overwrapper Machine Flat Seal Tray
Semi Automatic Servo Feeding Overwrapper Machine Flat Seal Tray
Specifications
Brand Name :
SICI AUTO
Model Number :
XQ-SW300
Certification :
CE
Place of Origin :
Wuxi
MOQ :
1 set
Payment Terms :
T/T
Supply Ability :
30 set/month
Delivery Time :
30 work days
Packaging Details :
Wooden Case
Name :
Gift Box Semi-automatic Overwrapping Machine
Feeding mode :
by hand
Speed :
15-20pcs/min
Available box dimension :
(55-320) mm × (40-230) mm × (20-110) mm
Sealing type :
flat seal
Film feeding mode :
servo feeding
Power :
3kw
Voltage :
220v/380v
Optional :
heating plate
Application :
perfume, tea, toys
Description

Semi-automatic Gift Box Overwrapping Machine with Servo Feeding

Overwrapping Machine Introduction

The cellophane wrapping machine is a widely-used automatic Bopp film overwrapping machine for cartons, boxes, and cases. Cellophane wrappings are fashionable, dust-proof, value-improved for your products. Semi-automatic overwrapping machine is cost-effective suitable for smaller plant to provide production.

Technical Parameter

Model XQ-SW300
Packing Size (55-320) mm × (40-230) mm × (20-110) mm
Production Capacity 15-20 packs / min
Total Power 3kw
Working Voltage 220V
Compressed Air 0.4-0.8Mpa
Machine Weight 180kg
Machine Dimensions 2000 (mm) × 800 (mm) × 1100 (mm)

Machine Principle

Semi Automatic Servo Feeding Overwrapper Machine Flat Seal Tray

Overwrapping Machine Features

Model:XQ-SW300 Semi-automatic Gift Box Overwrapping Machine with Servo Feeding

1. The specific heat shrink packaging machine greatly improves the packaging yield and decorative effect, enhances the market competitiveness of the packaged products, can greatly increase the sales volume, and increase the added value of the products.

2. Stable operation, high reliability, almost no maintenance.

3. More than 80% energy saving than the heat shrink packaging machine. You can purchase a semi-automatic transparent film packaging machine for the electricity saved in the next year.

Packing Material Requirements

Packaging material

BOPP shrink film in roll; ID¢76mm; thickness: 0.025 mm

Width: according to box size

heat-seal temperature: 100℃-150℃
Drawstring

Self-adhesive

A: width: 1.2-3mm

B: breaking strength: 10N-15N

C: thermal shrink film: ≤2.5℅

D: diameter: 35mm

E: heat-seal temperature: 100℃-150℃
Packing products The shape must be square, the paste is firm, and there must be no flanging, wrong side, misplacement, softness, etc.

Samples

Semi Automatic Servo Feeding Overwrapper Machine Flat Seal TraySemi Automatic Servo Feeding Overwrapper Machine Flat Seal Tray
