Cigarette Tobacco Automatic Carton Erector Servo Case Erectors
Cigarette Tobacco Automatic Carton Erector Servo Case Erectors
Cigarette Tobacco Automatic Carton Erector Servo Case Erectors
Cigarette Tobacco Automatic Carton Erector Servo Case Erectors
Cigarette Tobacco Automatic Carton Erector Servo Case Erectors
Cigarette Tobacco Automatic Carton Erector Servo Case Erectors
Specifications
Brand Name :
SICI AUTO
Model Number :
XQ-KX-400
Certification :
CE
Place of Origin :
Wuxi
MOQ :
1 set
Payment Terms :
T/T
Supply Ability :
50 set/ month
Delivery Time :
30 work days
Packaging Details :
Wooden Case
Name :
Servo Carton Erector Machine
Adhesive Tape Width :
60/75mm
Sealing Type :
adhesive tape
Speed :
12ctn/min
Power :
2050W
Voltage :
220V 50/60Hz
Available dimension :
(250-460) * (150-400) * (100-400) mm
Application :
medicine, beverages, electronics
Carton Storage Quantity :
80-100pcs (800-1000mm)
Machine Dimension :
L2150mm×W2150mm×H1750mm
Description

Cigarette Box XQ-KX-400 Servo Carton Erector Machine for Tobacco

Carton Erector Machine Introduction

Automatic servo vertical box machine is a kind of automatic grasping through suction cups, one-click switching automatic adjustment of carton size, and automatic molding equipment. The fully automatic carton erector machine has been widely used in food, medicine, beverage, tobacco, daily chemical, electronics, packing & printing and other industries.

The whole machine adopts electric eye automatic induction, servo and drive control unpacking design, which is faster and more stable to open the box, install safety protection doors, and replace the tape after opening the doors, which is more convenient and worry-free.

Technical Parameter

Model XQ-KX-400
Carton Opening Speed 12ctns/min
Carton Size L250-460mm×W150-400mm×H100-400mm
Power Supply 220V 50/60Hz 1Phase
Power 2050W
Adhesive Tape Width 60/75mm
Carton Storage Quantity 80-100pcs (800-1000mm)
Air Consumption 45ONL/min
Air Compressing 6kg/cm3
Table Height 620+30 mm
Machine dimension L2150mm×W2150mm×H1750mm
Machine Weight 450Kg

Machine Principle

Cigarette Tobacco Automatic Carton Erector Servo Case Erectors

Carton Erector Machine Features

Model: XQ-KX-400 Cigarette Box Servo Carton Erector Machine for Tobacco

1. High unpacking efficiency: servo control system, one-button switch can automatically adjust the size of the carton, the whole process of unmanned operation, fast and stable unpacking, 12 boxes / min.
2. Durable parts: Use durable parts, electrical components, pneumatic components.
3. Can be used in combination: can be operated alone or with automatic packaging lines.
4. Labor saving: The packaging of goods is done with machines instead of labor.
5. Safer: Increase the alarm prompt of broken belt, and the door will stop automatically to avoid misoperation.

6. The whole machine adopts strict Production process parts and servo drive unpacking, the speed is up to 12 boxes/min, the carton is automatically picked up and formed, and the automatic alarm prompt function of broken tape and no tape is added
