UL2587 4C×2.5mm2 Bare Copper Stranded Cable With PVC Insulation PVC Jacket 600V
UL2587 4C×2.5mm2 Bare Copper Stranded Cable With PVC Insulation PVC Jacket 600V
UL2587 4C×2.5mm2 Bare Copper Stranded Cable With PVC Insulation PVC Jacket 600V
UL2587 4C×2.5mm2 Bare Copper Stranded Cable With PVC Insulation PVC Jacket 600V
Specifications
Payment Terms :
T/T,L/C,Western Union
Color :
Black/Customized
Name :
Copper Stranded Cable
Delivery Time :
3-4 Weeks
Jacket :
PVC
Price :
To be negotiated
Brand Name :
Shineplus
Insulation :
PVC
Temperature :
-25-90℃
Place of Origin :
China
Voltage :
600V
Model Number :
UL2587
SP :
2601924
Packaging Details :
Packed in rolls or reels
MOQ :
1000m
Certification :
RoHS
Conductor :
Bare Copper Stranded
Supply Ability :
100km per day
Application :
Industrial,comsumer Electrics,etc
Description

UL2587 4C×2.5mm2 Bare Copper Stranded Industrial Cable With PVC Insulation PVC Jacket 600V

Construction
Conductor Bare copper stranded
Cross section 2.50mm2
Construction 140/0.15mm
Strand Dia. 2.05mm
Insulation PVC
Nom.Thickness 0.76mm
Min.Thickness 0.69mm
Insulation Dia. 3.70±0.15mm
Insulation colour 1-3.black print number 1-3 4.green/yellow
Material Non-woven
Filler Optional
Assembly 4C×2.5mm2+W
Inner Jacket PVC
Nom.Thickness 0.76mm
Min.Thickness 0.61mm
O.D. 11.00±0.30mm
Colour black
Braid Tinned copper,0.127mm,≥85%
Jacket PVC(Oil resistant and UV resistant)
Nom.Thickness 0.76mm
Min.Thickness 0.61mm
O.D. 14.00±0.50mm
Colour Per request

Product Description

Application: Internal wring or external interconnection of electronic equipment.
Application standard: Outdoor or machine
Product character:

Tensile strength:≥10.3MPa Elongation:≥100%

Aged condition:121±1℃×168h

Percent of original tensile strength: ≥70%

Percent of original elongation: ≥45%

Insulation:PVC
Conductor : Bare copper stranded
Construction
Insulation: 1-3.black print number 1-3 4.green/yellow
Jacket Color : black

Application
These cables are appropriate for flexible use with medium mechanical stresses, and free movement without tensile stress or forced movements in dry, moist and wet rooms but not open air. Suitable to be used as measuring and control cables in tool machines,

Standards
International:UL2587
RoHS

VW-1


Technical data
Rated voltage:600V
Rated Temperature: -25-90℃
Max.conductor DC resistance(20℃):7.98Ω/km
Dielectric Strength AC:2.0kV/1min

Properties
Effectively resist electromaganetic interference
Excellent insulation performance
Extensively Flame resistant
Flexible
