High Capacity Cable Cut Strip Machine Electronic Wire Stripping Machine
High Capacity Cable Cut Strip Machine Electronic Wire Stripping Machine
High Capacity Cable Cut Strip Machine Electronic Wire Stripping Machine
High Capacity Cable Cut Strip Machine Electronic Wire Stripping Machine
High Capacity Cable Cut Strip Machine Electronic Wire Stripping Machine
High Capacity Cable Cut Strip Machine Electronic Wire Stripping Machine
High Capacity Cable Cut Strip Machine Electronic Wire Stripping Machine
High Capacity Cable Cut Strip Machine Electronic Wire Stripping Machine
High Capacity Cable Cut Strip Machine Electronic Wire Stripping Machine
High Capacity Cable Cut Strip Machine Electronic Wire Stripping Machine
High Capacity Cable Cut Strip Machine Electronic Wire Stripping Machine
High Capacity Cable Cut Strip Machine Electronic Wire Stripping Machine
Specifications
Payment Terms :
L/C,D/A,Western Union,T/T,D/P
Motors & Drives :
6 sets of Servo Motors & Drives
Weight :
300KG
Model Number :
HR-02DS
Production Capacity :
18AWG-32AWG, 8-wire: Approx. 8,000 pcs/hour14AWG-32AWG, 5-wire: Approx. 5,000 pcs/hour
MOQ :
1
Delivery Time :
Within 5 Working Days
Ball Screws :
Brand: TBI Motion (Taiwan)
Tinning Length :
1-10mm (Customizable beyond range)
Brand Name :
JunSheng
Cutting Length :
20-1000mm (Customizable beyond range)
Packaging Details :
Wooden Box
Cylinders :
Brand: Airtac (Taiwan)
Price :
5650
Display Screen :
High-definition Screen, Brand: We-con
Voltage :
220V
Supply Ability :
200
Wire Range :
18AWG-32AWG (8-wire);14AWG-32AWG (5-wire)
Twisting Length :
3-10mm (Customizable beyond range)
Place of Origin :
China
Linear Guides :
Brand: HIWIN (Taiwan)
Certification :
CE /ISO
Front/Rear Stripping Length :
1-10mm (Customizable beyond range)
Description
Automatic Cat5e Cable Wire Stripping Twisting and Soldering Machine
Download Technical Specifications
Key Features
  • Dual Wire Processing Modes & Wide Wire Compatibility: Supports 5-wire simultaneous processing for 14AWG-32AWG cables and 8-wire processing for 18AWG-32AWG cables, covering most common thin electronic wire sizes.
  • Adjustable Multi-Size Processing Parameters: Fully customizable dimensions including cutting length (20mm-1000mm), front & rear stripping length (1-10mm), twisting length (3-10mm), and tinning length (1-10mm).
  • High Efficient Production Capacity: Stable output of approximately 5,000 pieces per hour for 5-wire processing and up to 8,000 pieces per hour for 8-wire processing.

Exhibition & Quality Assurance
High Capacity Cable Cut Strip Machine Electronic Wire Stripping Machine High Capacity Cable Cut Strip Machine Electronic Wire Stripping Machine High Capacity Cable Cut Strip Machine Electronic Wire Stripping Machine
