Site Temporary Modular Prefabricated Office Building Waterproof Custom
Site Temporary Modular Prefabricated Office Building Waterproof Custom
Site Temporary Modular Prefabricated Office Building Waterproof Custom
Site Temporary Modular Prefabricated Office Building Waterproof Custom
Site Temporary Modular Prefabricated Office Building Waterproof Custom
Site Temporary Modular Prefabricated Office Building Waterproof Custom
Site Temporary Modular Prefabricated Office Building Waterproof Custom
Site Temporary Modular Prefabricated Office Building Waterproof Custom
Specifications
Brand Name :
YAGO INDUSTRY
Model Number :
YGCY10
Packaging Details :
By Pallet or As Request
Dimension :
Length 6058mm. Width 2438mm. Height 2896mm
Delivery Time :
25-45Days
M2 :
14.77
Place of Origin :
China
Certification :
ISO;CE
MOQ :
6units
Payment Terms :
T/T,L/C
Supply Ability :
1500-2000units/month
Description
Simple Strong Modular Building Easy Setup Waterproof Temporary Living Work Structure
Product Introduction

This simple strong modular building is an easy setup, waterproof temporary living and work structure. It features a sturdy structure, convenient installation, reliable waterproof performance, and provides safe, practical space for temporary accommodation, on-site office, and field work use.

Product Description

This simple strong modular building is designed as an all-purpose easy setup waterproof temporary living work structure. The whole unit adopts factory prefabricated flat-pack design, which is simple in structure and strong in stability, greatly reducing transportation and installation costs. With professional waterproof treatment on the roof and wall joints, it effectively prevents rainwater leakage and adapts to outdoor long-term use. The galvanized steel frame ensures high structural strength and long service life. It can be quickly assembled on site without complex tools or construction work, making it ideal for emergency situations, remote sites, and temporary projects. The interior space is flexible and can be used for both living and working, meeting diversified temporary space demands.

Application Scenarios
  • Construction site temporary dormitory and duty room
  • Field work and exploration team temporary housing
  • Emergency rescue and disaster relief temporary shelter
  • Small temporary office, storage room, and workshop
  • Outdoor temporary working and resting space
Specifications
Project name: Flatpack Container 6.06*2.435*2.89m
A Item Specification
Steel Frame System System
1 Roof structure Main roof frame: Q235 galvanized Steel profile, with Automatic Powder Coated paint Roof purlin: C Section Steel, galvanized. Q235B steel
2 Floor structure Main floor frame: Q235 galvanized Steel profile,with Automatic Powder Coated paint Floor purlin:C Section Steel, galvanized. Q235B steel
3 Corner pillar Q235 galvanized Steel profile, Galvanized with Automatic Powder Coated paint
Container roof System
1 Roof covering Galvanized Powder Coated color painting steel Sheet.
2 Insulation Fiber glass with aluminum foil
3 Ceiling board Galvanized Powder Coated color painting steel Sheet.
Container floor System
1 PVC flooring Vinly floor leather with glue
2 Floor board 18mm fiber cement board
ContainerWall System
1 Wall panel 50mm /75mm fireproof Mineral Rockwool Sandwich panel
2 Door Insulated Steel Door
3 Window PVC sliding window, double glass, with fly screen
Container Electrical System
1 Power distribution cabinet Circuits with air-break switch, leakage protector,
2 Light LED light, 24W
3 AC Socket 16A universal, with socket box
4 Common Socket 10A, Universal type, with socket box
5 Switch 10A , with switch box
Plumbing system(Optional as per drawing)
1 washbasin including the accessory
2 Closetool including the accessory
3 shower shower base, shower head, water mixture
4 Exhaust Fan 6 Inch
5 water pipe input and output water pipe
Stair case and Corridor. (Optional as per drawing)
1 Stair Case and Corridor Fabricated with C channel steel, square tube, Round Steel, And checkered Steel Plate
Additional Traingle Roof on Top of Each Block. (Optional as per drawing)
1 Roof Structure Fabricated with C section steel, Galvanized Q235 Steel.
2 Roof Covering Corrugated Galvanized Powder Coated Roof Tile
Advantages
  • Simple structure: Easy to transport, install and maintain
  • Strong & durable: Stable steel frame, long service life
  • Easy setup: Fast assembly without professional workers
  • Super waterproof: Reliable leak-proof design for outdoor use
  • Multi-purpose: Suitable for both temporary living and working
  • Cost-effective: Low investment, reusable, high efficiency

    Site Temporary Modular Prefabricated Office Building Waterproof Custom

    Site Temporary Modular Prefabricated Office Building Waterproof Custom

FAQ

Q: Do we need professional workers to install this modular building?

A: No, it is designed for easy setup; 2–3 workers can finish assembly quickly with simple tools.

Q: How is the waterproof performance in heavy rain seasons?

A: It adopts integrated waterproof structure and sealed joints, performing well in continuous heavy rain.

Q: Can this building be used as both living room and office?

A: Yes, the flexible interior layout supports living, working, storage and other functions.

Q: Is it suitable for use on soft ground such as grass or sand?

A: With proper base support or adjustable footing, it can be stably placed on flat grass, sand and gravel ground.

Q: Can we add extra windows or doors for better ventilation?

A: Yes, we support customizing the number, size and position of doors and windows to meet ventilation needs.
