Specifications
Model Number :
YGCY37
Payment Terms :
T/T,L/C
Dimension: :
Length 6058mm. Width 2438mm. Height 2896mm
MOQ :
6 Units
Packaging Details :
By Pallet or As Request
Supply Ability :
1500-2000 Units
Delivery Time :
25-45 Days
M2: :
14.77
Certification :
ISO;CE
Place of Origin :
China
Brand Name :
YAGO INDUSTRY
Description
Economical Sturdy Prefabricated Building Weather Resistant Fast Assemble Onsite Worker Housing Unit
Product Introduction

This economical sturdy prefabricated building is a weather‑resistant, fast‑assemble onsite worker housing unit. Balancing competitive cost and solid mechanical performance, it offers reliable temporary living quarters for project crews under diverse outdoor site conditions.

Description

This economical sturdy prefabricated building is a cost‑optimized weather resistant fast assemble onsite worker housing unit manufactured by YAGO Industry. Adopting mature flat‑pack modular prefabrication technology, major structural components are finished inside the factory to cut field workload. The heavy‑duty galvanized steel frame creates sturdy anti‑deformation performance, while matched weather‑proof sandwich panels defend against wind, rain and UV exposure. It features bolt‑only fast assemble without complicated welding work, lowering both labor requirement and overall project investment. This prefabricated building can be used standalone or grouped to build large‑size onsite worker camps. With simplified but practical interior layout, it meets basic daily living requirements for site staff, being a budget-friendly yet dependable onsite housing option for various engineering projects.

Application Scenarios
  • Short‑term infrastructure project onsite worker dormitory
  • Budget‑controlled temporary staff housing for highway & road construction
  • Remote field project economical worker camp
  • Commercial building site mass worker accommodation
  • Transitional temporary housing for post‑disaster reconstruction sites
Specifications
Project name: Flatpack Container 6.06*2.435*2.89m
A Item Specification
Steel Frame System System
1 Roof structure Main roof frame: Q235 galvanized Steel profile, with Automatic Powder Coated paint Roof purlin: C Section Steel, galvanized. Q235B steel
2 Floor structure Main floor frame: Q235 galvanized Steel profile,with Automatic Powder Coated paint Floor purlin:C Section Steel, galvanized. Q235B steel
3 Corner pillar Q235 galvanized Steel profile, Galvanized with Automatic Powder Coated paint
Container roof System
1 Roof covering Galvanized Powder Coated color painting steel Sheet.
2 Insulation Fiber glass with aluminum foil
3 Ceiling board Galvanized Powder Coated color painting steel Sheet.
Container floor System
1 PVC flooring Vinly floor leather with glue
2 Floor board 18mm fiber cement board
ContainerWall System
1 Wall panel 50mm /75mm fireproof Mineral Rockwool Sandwich panel
2 Door Insulated Steel Door
3 Window PVC sliding window, double glass, with fly screen
Container Electrical System
1 Power distribution cabinet Circuits with air-break switch, leakage protector,
2 Light LED light, 24W
3 AC Socket 16A universal, with socket box
4 Common Socket 10A, Universal type, with socket box
5 Switch 10A , with switch box
Plumbing system(Optional as per drawing)
1 washbasin including the accessory
2 Closetool including the accessory
3 shower shower base, shower head, water mixture
4 Exhaust Fan 6 Inch
5 water pipe input and output water pipe
Stair case and Corridor. (Optional as per drawing)
1 Stair Case and Corridor Fabricated with C channel steel, square tube, Round Steel, And checkered Steel Plate
Additional Traingle Roof on Top of Each Block. (Optional as per drawing)
1 Roof Structure Fabricated with C section steel, Galvanized Q235 Steel.
2 Roof Covering Corrugated Galvanized Powder Coated Roof Tile
Advantages
  • Economical cost: Optimized structural design for budget‑sensitive projects
  • Sturdy construction: Robust galvanized steel frame against deformation
  • Weather resistant: Good resistance to wind, rain and outdoor ultraviolet rays
  • Fast assemble: Bolt‑connected design, less manpower needed on‑site
  • Practical modularity: Can be expanded into large‑scale worker camps
  • Convenient turnover: Easy disassembly for reuse on subsequent projects
Economical Sturdy Prefabricated Building Weather Resistant Fast Assemble Onsite Worker Housing Unit Economical Sturdy Prefabricated Building Weather Resistant Fast Assemble Onsite Worker Housing Unit
FAQ

Q: What makes this housing unit more economical compared to higher‑spec camp units?

A: It adopts mature standardized material configuration without redundant high‑end fittings, while keeping core structural and weather‑proof performance intact to control overall costs.

Q: Can this sturdy prefabricated building hold up under continuous outdoor site exposure for several years?

A: Yes, the anti‑rust galvanized frame and weather‑resistant panels guarantee stable performance for 15‑20‑year service life under regular maintenance.

Q: Do we need special heavy‑duty tools for its fast‑assemble process?

A: Only common hand‑held bolt tools are required; no welding machines or large lifting equipment are necessary for regular assembly.

Q: Is this onsite worker housing unit suitable for projects with tight capital budgets and large housing quantities?

A: Absolutely. Its economical feature is designed for bulk procurement, ideal for projects that need dozens or hundreds of worker accommodation units.

Q: After finishing one project, can we take apart and reuse these units on another construction site?

A: Yes. The bolt‑connected structure enables non‑destructive disassembly. Units can be flat‑packed for shipment and reassembled at new job‑site locations.
