J3FM 0203505-05 Nylon bearing PTFE Plastic Flange Bearing
J3FM 0203505-05 Nylon bearing PTFE Plastic Flange Bearing
J3FM 0203505-05 Nylon bearing PTFE Plastic Flange Bearing
J3FM 0203505-05 Nylon bearing PTFE Plastic Flange Bearing
J3FM 0203505-05 Nylon bearing PTFE Plastic Flange Bearing
J3FM 0203505-05 Nylon bearing PTFE Plastic Flange Bearing
Specifications
Delivery Time :
10-15 work days
Type :
Sleeve, Flanged, Thrust Washer, Plate
Cost :
Affordable
Description :
Thermoplastic Plastic Bushing
Durability :
High
Usage :
Used for reducing friction between two moving parts
Precision :
CNC machined high precision
Oem :
YES
Installation Method :
Press-fit or snap-in
Maintenance :
Low maintenance required
Weight :
Lightweight
Temperature Resistance :
Can withstand high temperatures
Feature :
High Load,Corrosion Resistant
Corrosion Resistance :
Highly resistant to corrosion
Brand Name :
Joyreap
Certification :
ISO 9001
Place of Origin :
China
Payment Terms :
T/T
Chemical Resistance :
Resistant to most chemicals
MOQ :
100
Packaging Details :
Cardboard box/ 36*36*23cm
Supply Ability :
100000pcs/30 days
Material :
Plastic Nylon
Description
J3FM 0203505-05 Nylon Bearing PTFE Plastic Flange Bearing
Material: Peek/ABS/PP/PVC/PTFE/Nylon/Pom/Rubber
Color: Green, Yellow, Black, White
Thermal Properties
Max. long-term application temperature 90 °C
Max. short-term application temperature 120 °C
Lower application temperature -50 °C
Heat conductivity 0.25 W/m · K
Thermal expansion coefficient (at 23°C/73°F) 13 K–1 · 10–5 DIN53752
Mechanical Properties
Compressive strength 60 MPa
Max. recommended surface pressure 45 MPa
Maximum surface speed, oscillating, short-term 2.1 m/s
Maximum surface speed, rotating, continuous 1.5 m/s
Maximum surface speed, rotating, short-term 3 m/s
Maximum surface speed, oscillating, continuous 1.1 m/s
Maximum surface speed, linear, continuous 8 m/s
Maximum surface speed, linear, short-term 10 m/s
Key Advantages
  • Excellent anti-wear properties
  • Low friction performance
  • Long service life
