Specifications
Place of Origin :
Guangdong, China
Brand Name :
BOJKE
MOQ :
1
Model Number :
WR-R66
Certification :
CE
Price :
$14.8
Payment Terms :
T/T
Supply Ability :
150k
Delivery Time :
5~8 work days
Packaging Details :
kraft paper box with carton box;
Product name :
Retro Reflective Photoelectric Sensor
Description :
photoelectric sensor diffuse reflection, diffuse reflection photoelectric sensor
Usage :
Sensing and detection transparent object
Output :
NPN
Size :
22 x 33.5mm
Sensing range :
50~1000mm
Description

Square Retro Reflective Photoelectric Optic Sensors Retro-Reflective Photoelectric Sensor

Product Description
Product Name photoelectric sensor
Housing Material PC
Function detection transparent object
Package kraft box

Square Retro Reflective Photoelectric Sensor NPN Output Fiber Optic Photoelectric Sensor
Model No. WR-R66
Detection Type Retro reflection, detection transparent object
Detection Distance 5cm-100cm
Light Spot Size Ø15mm/100cm
Hysteresis Range <20%
Detection Object Transparent object
Repeat Accuracy <5%
Sensitivity Adjustment knob adjustment
Output Type NPN open collector
Switching Mode Light.on/ Dark.on switchable
Response Time <1ms
Response Frequency 1KHz
Light Source 700nm visible red light
Working Voltage DC 12~24V ±10%
Residue Voltage (Voltage drop) <3V
Max Load Current 100mA
Consumption (no-load) Current <25mA
Ambient Illumination Incandescent lamp ≤ 3000Lux; Sunlight ≤ 10000Lux
Ambient Temperature operation:-10℃~55℃；storage:-25℃~70℃,no freezing
Ambient Humidity operation: 35%~85% RH；storage:35%~95% RH no condensation
Protection Circuit polarity reversal protection/surge protection/short circuit protection
Protection Level IP65
Indicator Light Orange
Connection Type 3 core, 2 meter standard cable
Housing Material ABS+PC
Withstand Voltage AC 500V, 50/60Hz, 1 minute
Vibration Resistance 10～55Hz, dual amplitude 1.5mm, X/Y/Z directions each 2 hours
Impact Resistance 500m/S2, X,Y,Z directions each 3 times
Insulation Impedance Above 20MΩ (DC 500V megohmmeter)

FAQ
Q : What is the MOQ?
A : 1pcs for our own available designs
Q : Can I customize a special sensor?
A : Sure
Q : Can I get a lower price if I order large quantities?
A : Yes, Cheaper prices with bigger quantities orders
Q : Can I get a sample?
A : Of course, but you need to pay the sample fee
Q : When will you ship my order?
A : 3 day shipping guarantee for stock item and within 15 days for non-stock items.
Q : How about the quality guarantee period ?
A : Our warranty period is one year since from shipping date.
Q : Can I add or delete items from my order if I change mind?
A : Yes, but you need to tell us asap, if your order has been done in our production line, we cannot change it.
