Specifications
Brand Name :
BOJKE
Model Number :
PUD-200NP
Certification :
CE
Place of Origin :
Dongguan China
MOQ :
1pcs
Payment Terms :
T/T
Supply Ability :
150k
Delivery Time :
5~8 work days
Packaging Details :
kraft box with carton box;
Product name :
Transparent label sensor
Power supply :
DC 12~24V
Slot width :
0.35mm
Slot length :
85mm
Detected object :
Transparent or opaque labels
Response time :
less than 1ms
Repeatability :
less than 5%
Output :
NPN and PNP
Description

Label Sensor Detection Inspecting Counting Transparent Opaque Printed Labels

Product Name Capacitive label sensor
Housing material Aluminum alloy
Function detection labels

IP65 Transparent Label Sensor Detection Inspecting Counting Opaque Transparent Printed Labels

Infrared detection and ultrasonic detection and capacitive detection are available

Stably detects those labels with 0.35mm gaps and 85mm length
With two-point and single-point teaching function

Model PUD-200NP
Detection Mode capacitive sensing
Slot Wideth 0.35mm
Slot depth 85mm
Hysteresis Range <20%
Detection Object transparent and opaque label
Repeat Accuracy <5%
Sensitivity Adjustment button adjustable
Output Mode NPN and PNP two channel output at same time
Switch Mode NO/NC switchable
Response Time <1ms
Response Frequency 2KHz
Working Voltage DC 12~24V ±10%
Residue Voltage <2V (load current 50mA, cable 2 meter)
Max Load Current 100mA
Consumption (no-load) current <40mA
Ambient Temperature working:-10℃~55℃；storage:-25℃~70℃,no freezing
Ambient Humidity working:35%~85% RH；storage:35%~95% RH,no condensation
Protection Circuit polarity reversal protection/surge protection/ short circuit protection
Protection Level IP65
Indicator Light Red: working indicator light; Green: output indicator light
Connection Type 4-PIN connector
Housing Material aluminum alloy+anodized
Withstand Voltage AC 500V, 50/60Hz, 1 minute
Vibration Resistance 10～55Hz, dual amplitude 1.5mm, X/Y/Z directions each 2 hours
Impact Resistance 500m/S2, X,Y,Z directions each 3 times
Insulation Impedance above 20MΩ (DC 500V megohmmeter)
