RGB Color Separation Fiber Optic Photoelectric Color Mark Sensor Switch LED Color Code Sensor
RGB Color Separation Fiber Optic Photoelectric Color Mark Sensor Switch LED Color Code Sensor
RGB Color Separation Fiber Optic Photoelectric Color Mark Sensor Switch LED Color Code Sensor
RGB Color Separation Fiber Optic Photoelectric Color Mark Sensor Switch LED Color Code Sensor
RGB Color Separation Fiber Optic Photoelectric Color Mark Sensor Switch LED Color Code Sensor
RGB Color Separation Fiber Optic Photoelectric Color Mark Sensor Switch LED Color Code Sensor
RGB Color Separation Fiber Optic Photoelectric Color Mark Sensor Switch LED Color Code Sensor
RGB Color Separation Fiber Optic Photoelectric Color Mark Sensor Switch LED Color Code Sensor
RGB Color Separation Fiber Optic Photoelectric Color Mark Sensor Switch LED Color Code Sensor
RGB Color Separation Fiber Optic Photoelectric Color Mark Sensor Switch LED Color Code Sensor
Specifications
Place of Origin :
Guangdong, China
Brand Name :
BOJKE
MOQ :
1
Model Number :
BS-502 and BS-502LG
Certification :
CE
Payment Terms :
T/T
Supply Ability :
150k
Delivery Time :
5~8 work days
Packaging Details :
kraft paper box with carton box;
Product name :
RGB color separation
Description :
color mark sensor, RGB color separation fiber optic color sensor
Output :
NPN/PNP
Response time :
<1ms
Power supply :
DC12~24V ±10%
Response frequency :
1000HZ
Description

RGB Color Separation Fiber Optic Photoelectric Color Mark Sensor Switch LED Color Code

Product Description
Product Name color mark sensor
Material ABS
Function Identification mark, color etc
Package plastic box+inner box

RGB Color Separation Fiber Optic Photoelectric Color Mark Sensor Switch LED Color Code Sensor

Model No BS-502 BS-502LG
Operation Voltage DC 12~24V ±10%
Consumption (no-load) Current ≤35mA
Detection Range 18~28mm
Light Source RGB color, 4-element LED RGB blue light
Detection Mode color mode and color mark mode switchable
Response Time color mark:50us； color:130us
Response Frequency 1000Hz
Output Type NPN open collector
Max Input Current <50mA
Residue Voltage <1.5V
Switch Type color mark mode: ON when detected; Color mode: ON when consistent
Ambient Illumination Incandescent lamp ≤ 3000Lux; Sunlight ≤ 10000Lux
Ambient Temperature operation:-10℃~55℃；storage:-25℃~75℃,no freezing
Ambient Humidity operation: 35%~85% RH；storage:35%~95% RH no condensation
Protection Circuit short circuit protection
Protection Level IP65
Connection Type 4 core 2 meters standard cable
Housing Material PBT
Withstand Voltage AC 500V, 50/60Hz, 1 minute
Vibration Resistance 10～55Hz, dual amplitude 1.5mm, X/Y/Z directions each 2 hours
Impact Resistance 500m/S2, X,Y,Z directions each 10 times
Insulation Impedance Above 20M Ω (DC 500V megohmmeter)
