Long Distance Color Code Sensor Mark RS485 Output 200μS Response Time
Long Distance Color Code Sensor Mark RS485 Output 200μS Response Time
Long Distance Color Code Sensor Mark RS485 Output 200μS Response Time
Long Distance Color Code Sensor Mark RS485 Output 200μS Response Time
Long Distance Color Code Sensor Mark RS485 Output 200μS Response Time
Long Distance Color Code Sensor Mark RS485 Output 200μS Response Time
Long Distance Color Code Sensor Mark RS485 Output 200μS Response Time
Long Distance Color Code Sensor Mark RS485 Output 200μS Response Time
Long Distance Color Code Sensor Mark RS485 Output 200μS Response Time
Long Distance Color Code Sensor Mark RS485 Output 200μS Response Time
Long Distance Color Code Sensor Mark RS485 Output 200μS Response Time
Long Distance Color Code Sensor Mark RS485 Output 200μS Response Time
Specifications
Place of Origin :
Guangdong, China
Brand Name :
BOJKE
MOQ :
1
Model Number :
BS-W50N
Certification :
CE
Price :
$95
Payment Terms :
T/T
Supply Ability :
150k
Delivery Time :
5~8 work days
Packaging Details :
kraft paper box with carton box;
Type :
Color Code Sensor
Features :
Long-distance color recognition
Mounting Type :
manual installation
Description :
color mark sensor, Color mark photoelectric sensor
Manufacturer Part Number :
BS-500NP
Usage :
Industrial Automation
Theory :
Photoelectric Sensor
Output :
RS485
Response Time :
200μm
Voltage - Supply :
DC12~24V ±10%
Description

BOJKE RS485 Output 200μS Response Time Long-Distance Color Recognition Sensor Mark

Product Name Color mark sensor
Material Aluminum alloy
Function Recognize

Long Distance Color Code Sensor Mark RS485 Output 200μS Response Time
Model BS-W50N BS-W50P
Output Type NPN PNP
Type cable type
Conrol Output 1 output port, buit in short ciruit protection, and have automatic anti any interference function
Light Source white LED ,adjustable spot ,minium spot diameter 3.6MM
Response Time AUTO,C mode and CI mode 200us, at MARK mode 160us
Output Option LIGHT-ON/DARK-ON
Indicator Operation indicator light: red infrared, LED display screen
Detection Mode AUTO,C mod, CI mod and MARK mode sensing distance: 30MM—500MM
Timer OFF delay/ON delay/one-shot/ON one-shot timer optional,timer range(ms):1ms ~ 9999ms
Conrol Output NPN open collector/PNP open collector 24V ,Maximum 100mA
Max current consumption 40mA(when connect external, drop voltage:2V
Power Supply 12 ~ 24VDC±10%,ripple(P-P): ≤10％ class 2
Ambient Illuminace Incandescent lamp: 20,000lux or less Sunlight:30,000lux or less
Consumption Power Max Voltage:24V, Current within 60MA Max Voltage: 24V,Current within 60MA
Vibration Resistance 10 ~ 55Hz ,double amplitude 1.5mm ,2 hours in each of the X,Y,Z directions
Ambient Temperature - 10 ~ +55℃ , no freezing
