Smart Bluetooth Active Balancing BMS For Sodium Ion Battery 4S 100A 200A 300A
Smart Bluetooth Active Balancing BMS For Sodium Ion Battery 4S 100A 200A 300A
Smart Bluetooth Active Balancing BMS For Sodium Ion Battery 4S 100A 200A 300A
Smart Bluetooth Active Balancing BMS For Sodium Ion Battery 4S 100A 200A 300A
Smart Bluetooth Active Balancing BMS For Sodium Ion Battery 4S 100A 200A 300A
Smart Bluetooth Active Balancing BMS For Sodium Ion Battery 4S 100A 200A 300A
Smart Bluetooth Active Balancing BMS For Sodium Ion Battery 4S 100A 200A 300A
Smart Bluetooth Active Balancing BMS For Sodium Ion Battery 4S 100A 200A 300A
Smart Bluetooth Active Balancing BMS For Sodium Ion Battery 4S 100A 200A 300A
Smart Bluetooth Active Balancing BMS For Sodium Ion Battery 4S 100A 200A 300A
Smart Bluetooth Active Balancing BMS For Sodium Ion Battery 4S 100A 200A 300A
Smart Bluetooth Active Balancing BMS For Sodium Ion Battery 4S 100A 200A 300A
Specifications
Number of LFP Series :
4S
Continuous Discharge :
100A 200A 300A
Application :
Electric Bicycles/Scooters
MOQ :
1
Balancing Current :
0~2A
Place of Origin :
Guangdong, China
Overcurrent Protection (Adjustable) :
100-600A
Max Discharge(Adjustable) :
100A-350A
Brand Name :
ENJBMS
Balancing Method :
Active Balancing
Model Number :
ENJBMS2A4S200A
Price :
$72-120
Description

Item Specification

Designed specifically for sodium-ion batteries (Na-ion), not Li-ion

Smart Bluetooth Active Balancing BMS For Sodium Ion Battery 4S 100A 200A 300A
Basic Configuration
Function
Configuration
Number of strings supported
4S
Continuous current
50A-300A
Number of NTCs
2 built in, 4 external
Balance Function
Active balancer 1A-3A
UART (non isolated)
Standard
Switch function
Optional (With/ Without)
Charging current limit
Optional (With/ Without)
Battery packs in parallel
Yes
History record
Optional (With/ Without)
LCD display
Optional (With/ Without)
Bluetooth
Optional (With/ Without)
Heating function
Optional (With/ Without)
CAN communication
Optional (With/ Without)
RS485 communication
Optional (With/ Without)
Electrical parameters
Item Symbol Content Criterion
Over charge Protection VCU1 Over charge detection voltage 4.0+0.025V (settablel)
tCU1 Over charge 1st detection delay time 1+0.5S (settable)
VCL1 Over charge 1st release voltage 3.8+0.05V (settable)
Over discharge protection VDL Over discharge detection voltage 2.0+0.08V (settable)
tDL Over discharge detection delay time 1+0.5S (settable)
VDU Over discharge release woltage 4.20+0.1V (settablel
Continue current ICHG Continue charge current 50A-100A (settable)
IDIS Continue discharge current 50A-300A (settable
Over current protection OCIOV1 Charge overcurrent detection current 1 300A (settable)
ODIOV1 Discharge overcurrent detection current 1 1000A (settable)
Short current protection ISHORT Short circuit detection current Yes
tSHORT Short circuit delay time 500US
Over Short current release / Over current & short current release Load disconnection
Balance function VBAL Balance detection voltage 3.0v (settable)
Balance release current 2000mA
Temperature protection NTC NTC discharge temperature protection 40-85 (settable)
Internal resistance RCHG Resistance in charge <50mohm
RDIS Resistance in discharge <50mohm
Current consumption ISTB Current consume in normal operation <2250uA

Products Description

Smart Bluetooth Active Balancing BMS For Sodium Ion Battery 4S 100A 200A 300A
Smart Bluetooth Active Balancing BMS For Sodium Ion Battery 4S 100A 200A 300A
Smart Bluetooth Active Balancing BMS For Sodium Ion Battery 4S 100A 200A 300A
Smart Bluetooth Active Balancing BMS For Sodium Ion Battery 4S 100A 200A 300A
Smart Bluetooth Active Balancing BMS For Sodium Ion Battery 4S 100A 200A 300A
Smart Bluetooth Active Balancing BMS For Sodium Ion Battery 4S 100A 200A 300A
Smart Bluetooth Active Balancing BMS For Sodium Ion Battery 4S 100A 200A 300A
