Lifepo4 High Voltage Battery BMS 240S 768V 10X 24S 314Ah Stackable MPPT Tracker BMS

Specifications

Voltage :

768V

Application :

Solar Energy Storage Systems, Industrial

Balancing type :

active balance

Place of Origin :

Guangdong, China

Brand Name :

ENJ

Communication :

RS485/CANbus/UART/BT/WIFI

MOQ :

Battery type :

LFP NCM LTO Sodium Li-ion

Price :

$1,079

Model Number :

ENJBMS2A24SR

Description

Lifepo4 High Voltage Battery BMS 240S 768V 10X 24S 314Ah Stackable MPPT Tracker BMS

Technical indicators	Product number
Technical indicators	EJBMS2A24SR200	EJBMS2A24SR500
Number of LFP strings	4~24	4~24
Balanced approach	Active balance
Balanced current	0~2A	0~2A
Continuous discharge current	200A	500A
Maximum discharge current (adjustable)	400A	1000A
Overcurrent protection (adjustable)	500A	1200A
Outlet method	Common Port
Overcharge protection voltage (adjustable)	3.75V or 4.2V (adjustable)
Overcharge release voltage (adjustable)	3.60V
Overcurrent release time (adjustable)	1S
Over-discharge protection voltage (adjustable)	2.50V
Over-discharge recovery voltage (adjustable)	3.00V
Maximum number of temperature detections	4 pcs
Short circuit protection	YES
coulomb meter	YES
Display interface	Optional
RS485 communication interface	Optional
RS232 communication interface	Optional
CAN communication interface	Optional
Temperature interface	Optional
Heating interface	Optional
Bluetooth interface	Optional

Lifepo4 High Voltage Battery BMS 240S 768V 10X 24S 314Ah Stackable MPPT Tracker BMS

http://www.enjpower.com/productview_138.htm

Lifepo4 High Voltage Battery BMS 240S 768V 10X 24S 314Ah Stackable MPPT Tracker BMS

What are the key features that a ENJBMS should have?

Safety: ENJBMS have features to ensure the safe operation of the lithium battery, such as over-charge protection, over-discharge protection,over-temperature and short-circuit protection.

Accuracy: ENJBMS provide accurate voltage, current, and temperature readings to allow for proper battery monitoring and management.

Flexibility: ENJBMS support various types of lithium battery chemistries(like LiFePO4, LTO, NMC Li-ion) and be adaptable to different battery configurations and sizes.

Reliability: ENJBMS have a robust design and be able to operate consistently and accurately over an extended period of time.

Communication: ENJBMS have a reliable communication interface, such as Bluetooth or RS232, WiFi, I2C, CAN, or RS485, to allow for easy integration with other system components and monitoring software.

Scalability: ENJBMS can scalable to accommodate future growth and changes in battery requirements. Support further software upgraded by bluetooth or ENJBMS PC software.

Cost-effectiveness: ENJBMS have a good balance between performance and cost, and be a cost-effective solution for the specific battery application.

These are the main characteristics that a top-performing Lithium Battery Management System should have.

Lifepo4 High Voltage Battery BMS 240S 768V 10X 24S 314Ah Stackable MPPT Tracker BMS
