Extruder Screen Rim Pack Woven Wire Cloth Wholesale Wire Mesh Fabric
Extruder Screen Rim Pack Woven Wire Cloth Wholesale Wire Mesh Fabric
Extruder Screen Rim Pack Woven Wire Cloth Wholesale Wire Mesh Fabric
Extruder Screen Rim Pack Woven Wire Cloth Wholesale Wire Mesh Fabric
Specifications
Brand Name :
BM
Model Number :
FM
Certification :
CE
Place of Origin :
CHINA
MOQ :
1 EA
Price :
$0.2-$3.6
Payment Terms :
T/T, L/C, Western Union, MoneyGram
Supply Ability :
20000 Pcs Per Week
Delivery Time :
7-10 Days After Get The Advanced Payment
Packaging Details :
Plastic Film And Case
Material :
Stainless Steel201 304 316
Frame :
Aluminum,Stainless Steel
Shape :
Round ,Rectangle etc
Feature :
Smooth Surface
Wire Diameter :
0.02-2.0MM
Size :
As Requirement
Description

Extruder Screen Rim Pack Woven Wire Cloth Wholesale Wire Mesh Fabric

Stainless steel mesh and wire mesh screens are our main product. With many years of experiences , we serve worldwide our customer with premium quality and services.

Product Description

Material:

(1)Stainless Steel Mesh (SS 304,SS 304L,SS 316,SS 316L)

(2)Copper Mesh (Red copper Mesh,Brass Wire Mesh,Phosphor Bronze Wire Mesh)

(3)Low Carbon Steel Mesh

(4)Aluminum Mesh.

Product Application

Plastic Extruder Screens are made of Metal Woven Wire Mesh.Extruder Screens are an imperative

part of the melt filtration and extrusion process.It is effect to keeps away mixing of foreign particles in

finally equipped extrusion product and provide a clean and clear extrusion for plastic and rubber

processing machinery.

Product Features

(1) smooth surface with no sharp edges, burrs or acute angles.

(2) Anti-abrasive & anti-corrosive in nature, and high filtration capacity.

(3)Available in different size and variants according customers order.

Shape:Round,Circular,Rectangle,Oval and other shapes according to customers'requests.

Layers: Single layer,two layers,multi-layers.

Edge: With or Without Framework.

Woven Mesh Range

(1)Wire Diameter:0.025-3.4mm

(2)Aperture Size:0.026-23.4mm

(3)Weave Type:Plain Weave (3-300 Mesh); Twilled Weave(20-635 Mesh); Dutch Weave (7x40mesh-325x2300 mesh)

Mesh/Inch Wire Diameter Aperture Open Area Weight(LB)/100 Square Foot
Inch MM Inch MM
1x1 .080 2.03 .920 23.37 84.6 41.1
2X2 .063 1.60 .437 11.10 76.4 51.2
3X3 .054 1.37 .279 7.09 70.1 56.7
4X4 .063 1.60 .187 4.75 56.0 104.8
4X4 .047 1.19 .203 5.16 65.9 57.6
5X5 .041 1.04 .159 4.04 63.2 54.9
6X6 .035 .89 .132 3.35 62.7 48.1
8X8 .028 .71 .097 2.46 60.2 41.1
10X10 .025 .64 .075 1.91 56.3 41.2
10X10 .020 .51 .080 2.03 64.0 26.1
12X12 .023 .584 .060 1.52 51.8 42.2
12X12 .020 .508 .063 1.60 57.2 31.6
14X14 .023 .584 .048 1.22 45.2 49.8
14X14 .020 .508 .051 1.30 51.0 37.2
16X16 .018 .457 .0445 1.13 50.7 34.5
18X18 .017 .432 .0386 .98 48.3 34.8
20X20 .020 .508 .0300 .76 36.0 55.2
20X20 .016 .406 .0340 .86 46.2 34.4
24X24 .014 .356 .0277 .70 44.2 31.8
30X30 .013 .330 .0203 .52 37.1 34.8
30X30 .012 .305 .0213 .54 40.8 29.4
30X30 .009 .229 .0243 .62 53.1 16.1
35X35 .011 .279 .0176 .45 37.9 29.0
40X40 .010 .254 .0150 .38 36.0 27.6
50X50 .009 .229 .0110 .28 30.3 28.4
50X50 .008 .203 .0120 .31 36.0 22.1
60X60 .0075 .191 .0092 .23 30.5 23.7
60X60 .007 .178 .0097 .25 33.9 20.4
70X70 .0065 .165 .0078 .20 29.8 20.8
80X80 .0065 .165 .0060 .15 23.0 23.2
80X80 .0055 .140 .0070 .18 31.4 16.9
90X90 .005 .127 .0061 .16 30.1 15.8
100X100 .0045 .114 .0055 .14 30.3 14.2
100X100 .004 .102 .0060 .15 36.0 11.0
100X100 .0035 .089 .0065 .17 42.3 8.3
110X110 .0040 .1016 .0051 .1295 30.7 12.4
120X120 .0037 .0940 .0064 .1168 30.7 11.6
150X150 .0026 .0660 .0041 .1041 37.4 7.1
160X160 .0025 .0635 .0038 .0965 36.4 5.94
180X180 .0023 .0584 .0033 .0838 34.7 6.7
200X200 .0021 .0533 .0029 .0737 33.6 6.2
250X250 .0016 .0406 .0024 .0610 36.0 4.4
270X270 .0016 .0406 .0021 .0533 32.2 4.7
300X300 .0051 .0381 .0018 .0457 29.7 3.04
325X325 .0014 .0356 .0017 .0432 30.0 4.40
400X400 .0010 .0254 .0015 .370 36.0 3.3
500X500 .0010 .0254 .0010 .0254 25.0 3.8
635X635 .0008 .0203 .0008 .0203 25.0 2.63
