Multilayer Weave Mesh Filter Disc
Multilayer Weave Mesh Filter Disc
Multilayer Weave Mesh Filter Disc
Multilayer Weave Mesh Filter Disc
Specifications
Brand Name :
BM
Model Number :
BM-SCREEN028
Certification :
CE,CCC
Place of Origin :
China
MOQ :
1 Piece
Price :
$0.2-$3.6
Payment Terms :
D/A, L/C, D/P, T/T, Western Union, MoneyGram,paypal
Supply Ability :
50000 Pcs Per Week
Delivery Time :
7-10 Days After Get The Deposite
Packaging Details :
Water-Proof Plastic Film And Wooden Case
Product Name :
Filter Disc Mesh
Material :
SUS304,316,316L
Mesh type :
Plain Weave And Dutch Weave
Technology :
Welding Spot
Feeature :
Flexible Working
Application :
Filtering
Tooling :
With Charge
Description

Circle Extruder Screens In Single Or Multilayer Keep Particles Out / Filter Disc Mesh

Filter Disc Mesh Description

Circle Extruder screen sare available in different size, variants and specifications. They are highly durable with robust structure and have features of anti-abrasive and anti-corrosive in single layer and Multi-layer

Single extruder screens Filter Disc

They are predominantly used in the extruded profiles and blown film industries where the contamination of the raw material is less and there is often lower pressure within the extruder head.

Multilayer extruder screens Filter Disc

Many single layer screens are assembled properly and spot welded with each other to form multilayer. It can be with or without selvage. Multilayer extruder screen is used for fine and thin level of extrusion to prevent the mixing of foreign particles. Multilayer Extruder Screen helps in making extrusion more clear and clean.

Mesh :10mesh-500mesh
Layer:single,double,multilayer.
Disc Diameter: 50mm -580mm
The different wire meshes are processing as per desired shapes and sizes; assembled properly and spot welded with each other to form multilayer.

Filter Disc Mesh Benifits

  • Highly durable with robust structure.
  • Anti-abrasive & anti-corrosive in nature.
  • High quality and filtration capacity.
  • Precise fitting filter elements.
  • Optimum cost-performance ratio.
  • Constant quality control during production

Filter Disc Mesh Detailed Specification

Mesh/Inch Wire Diameter Aperture Open Area Weight(LB)/100 Square Foot
Inch MM Inch MM
1x1 .080 2.03 .920 23.37 84.6 41.1
2X2 .063 1.60 .437 11.10 76.4 51.2
3X3 .054 1.37 .279 7.09 70.1 56.7
4X4 .063 1.60 .187 4.75 56.0 104.8
4X4 .047 1.19 .203 5.16 65.9 57.6
5X5 .041 1.04 .159 4.04 63.2 54.9
6X6 .035 .89 .132 3.35 62.7 48.1
8X8 .028 .71 .097 2.46 60.2 41.1
10X10 .025 .64 .075 1.91 56.3 41.2
10X10 .020 .51 .080 2.03 64.0 26.1
12X12 .023 .584 .060 1.52 51.8 42.2
12X12 .020 .508 .063 1.60 57.2 31.6
14X14 .023 .584 .048 1.22 45.2 49.8
14X14 .020 .508 .051 1.30 51.0 37.2
16X16 .018 .457 .0445 1.13 50.7 34.5
18X18 .017 .432 .0386 .98 48.3 34.8
20X20 .020 .508 .0300 .76 36.0 55.2
20X20 .016 .406 .0340 .86 46.2 34.4
24X24 .014 .356 .0277 .70 44.2 31.8
30X30 .013 .330 .0203 .52 37.1 34.8
30X30 .012 .305 .0213 .54 40.8 29.4
30X30 .009 .229 .0243 .62 53.1 16.1
35X35 .011 .279 .0176 .45 37.9 29.0
40X40 .010 .254 .0150 .38 36.0 27.6
50X50 .009 .229 .0110 .28 30.3 28.4
50X50 .008 .203 .0120 .31 36.0 22.1
60X60 .0075 .191 .0092 .23 30.5 23.7
60X60 .007 .178 .0097 .25 33.9 20.4
70X70 .0065 .165 .0078 .20 29.8 20.8
80X80 .0065 .165 .0060 .15 23.0 23.2
80X80 .0055 .140 .0070 .18 31.4 16.9
90X90 .005 .127 .0061 .16 30.1 15.8
100X100 .0045 .114 .0055 .14 30.3 14.2
100X100 .004 .102 .0060 .15 36.0 11.0
100X100 .0035 .089 .0065 .17 42.3 8.3
110X110 .0040 .1016 .0051 .1295 30.7 12.4
120X120 .0037 .0940 .0064 .1168 30.7 11.6
150X150 .0026 .0660 .0041 .1041 37.4 7.1
160X160 .0025 .0635 .0038 .0965 36.4 5.94
180X180 .0023 .0584 .0033 .0838 34.7 6.7
200X200 .0021 .0533 .0029 .0737 33.6 6.2
250X250 .0016 .0406 .0024 .0610 36.0 4.4
270X270 .0016 .0406 .0021 .0533 32.2 4.7
300X300 .0051 .0381 .0018 .0457 29.7 3.04
325X325 .0014 .0356 .0017 .0432 30.0 4.40
400X400 .0010 .0254 .0015 .370 36.0 3.3
500X500 .0010 .0254 .0010 .0254 25.0 3.8
635X635 .0008 .0203 .0008 .0203 25.0 2.63

Filter Disc Mesh Application


Coffee filtration
Oil & Fuel Filters
Suction line strainers
Pressure line filters
Filters for Polyester fiber production
Microfiber,leather
Woven fabrics,color masterbatch
Plastic and rubber ,PVC granulation
Sheet extrusion, carbon fiber
