Explosion Proof Centrifugal Fan , 90000m3/h High Static Pressure Blower
Explosion Proof Centrifugal Fan , 90000m3/h High Static Pressure Blower
Explosion Proof Centrifugal Fan , 90000m3/h High Static Pressure Blower
Explosion Proof Centrifugal Fan , 90000m3/h High Static Pressure Blower
Explosion Proof Centrifugal Fan , 90000m3/h High Static Pressure Blower
Explosion Proof Centrifugal Fan , 90000m3/h High Static Pressure Blower
Explosion Proof Centrifugal Fan , 90000m3/h High Static Pressure Blower
Explosion Proof Centrifugal Fan , 90000m3/h High Static Pressure Blower
Specifications
Brand Name :
XIANRUN BLOWER
Model Number :
ZR-HP SERIES
Certification :
CE, ISO 9001
Place of Origin :
XINXIANG
MOQ :
1
Price :
50-50000
Payment Terms :
L/C, D/A, D/P, T/T
Supply Ability :
10000
Delivery Time :
5-45DAYS
Packaging Details :
WOODEN PACKING
Name :
Industrial Axial Flow Fan
Blade material :
Stainless Steel,Cast Iron,Steel plate,Q345 (16Mn) manganese steel
Power :
5 - 350KW
Warranty :
1 Year
Voltage :
220V/380V/440V/480V/660V
Color :
Customer's Requirement
Air volume :
800 - 90000m3/h
Applications :
Cooling systems
Description

High Static Pressure Blower Fan With High Speed Blower anti Explosion Industrial High Pressure Blowers

High-pressure centrifugal fan is based on the principle that kinetic energy is converted into potential energy. It accelerates the gas with a high-speed rotating impeller, then slows down and changes the flow direction, so that the kinetic energy is converted into potential energy (pressure). In the single-stage centrifugal fan, the gas enters the impeller from the axial direction, and the gas changes to the radial direction when flowing through the impeller, and then enters the diffuser. In the diffuser, the gas changes its direction of flow causing a deceleration, which converts kinetic energy into pressure energy. The pressure increase mainly occurs in the impeller, followed by the diffuser process. In a multistage centrifugal fan, a reflow is used to drive the air flow into the next impeller to generate higher pressure.

Explosion Proof Centrifugal Fan , 90000m3/h High Static Pressure Blower

Key Features

  • Impeller diameter: 80~3500 mm
  • Speed of mainshaft: 760~2900 rpm
  • Pressure range: 9000~25425 Pa
  • Flow range: 3297~43305 m3/h
  • Air Temperature: 20~1000 Celsius degree

  • Material: Cast Iron, Carbon Steel, Stainless Steel.

  • Efficiency: 70%-90%

Applications

  • Cement
  • Industrial boiler
  • Power generation
  • Chemical processing
  • Combustion-support
  • Cooling systems
  • Corrosive gas
  • Dryer
  • Dust collection
  • Forced draft
  • Fume exhaust
  • General ventilation
  • Incineration
  • Induced draft

Explosion Proof Centrifugal Fan , 90000m3/h High Static Pressure Blower
