660V High Pressure Centrifugal Blower 316L Stainless Steel Centrifugal Fan Double Inlet
660V High Pressure Centrifugal Blower 316L Stainless Steel Centrifugal Fan Double Inlet
660V High Pressure Centrifugal Blower 316L Stainless Steel Centrifugal Fan Double Inlet
660V High Pressure Centrifugal Blower 316L Stainless Steel Centrifugal Fan Double Inlet
660V High Pressure Centrifugal Blower 316L Stainless Steel Centrifugal Fan Double Inlet
660V High Pressure Centrifugal Blower 316L Stainless Steel Centrifugal Fan Double Inlet
660V High Pressure Centrifugal Blower 316L Stainless Steel Centrifugal Fan Double Inlet
660V High Pressure Centrifugal Blower 316L Stainless Steel Centrifugal Fan Double Inlet
Specifications
Brand Name :
XIANRUN BLOWER
Model Number :
4-68 Model
Certification :
CE, ISO 9001
Place of Origin :
XINXIANG
MOQ :
1
Price :
50-50000
Payment Terms :
L/C, D/A, D/P, T/T
Supply Ability :
10000
Delivery Time :
5-45DAYS
Packaging Details :
WOODEN PACKING
Voltage :
220V/380V/440V/480V/660V
Blade material :
Stainless Steel,Cast Iron,Steel plate,Q345 (16Mn) manganese steel
Air volume :
800 - 90000m3 / h
Power :
5 - 350KW
Warranty :
1 Year
Color :
Customer's Requirement
Material :
Steel,316L,Carbon Steel /Stainless Steel,Q235
Type :
Centrifugal Fan,Multi-wings Industrial Centrifugal Exhaust Blower Fan,centrifugal blower,high pressure blower
Applications :
Cooling systems
Name :
Industrial Axial Flow Fan
Description

High volume air blower backward curved centrifugal fans double inlet centrifugal fan boiler centrifugal fan

G4-68 Model high volume air blower backward curved centrifugal fans and induced draft fan are suitable for the ventilation and ventilating of steam boilers below 230T /h in thermal power plants. In the absence of other special requirements, G4-68 can also be used for mine ventilation and general ventilation. Both types of fans have the advantages of high efficiency, low noise and high strength. The medium transported by the ventilator is air, and the maximum temperature does not exceed 80℃; The medium transported by the induced draft fan is flue gas, and the maximum temperature shall not exceed 250 ° C. There are 7 machine numbers from No.8 to No.16.

660V High Pressure Centrifugal Blower 316L Stainless Steel Centrifugal Fan Double Inlet

660V High Pressure Centrifugal Blower 316L Stainless Steel Centrifugal Fan Double Inlet

660V High Pressure Centrifugal Blower 316L Stainless Steel Centrifugal Fan Double Inlet

Key Features

  • Impeller diameter: 90~3500 mm
  • Speed of mainshaft: 560~2900 rpm
  • Pressure range: 3000~25425 Pa
  • Flow range: 1297~83305 m3/h
  • Air Temperature: 20~1000 Celsius degree

  • Material: Cast Iron, Carbon Steel, Stainless Steel.

  • Efficiency: 80%-90%

Applications

  • Cement
  • Industrial boiler
  • Power generation
  • Chemical processing
  • Combustion-support
  • Cooling systems
  • Corrosive gas
  • Dryer
  • Dust collection
  • Forced draft
  • Fume exhaust
  • General ventilation
  • Incineration
  • Induced draft

Please advise us the USAGE and following Parameter.Our engineering Dept will recommend the most suitable product for you.

Air volume/air flow m3/h
Total pressure or static pressure Pa
Medium temperature °c
Voltage V
Frequency Hz
Altitude of operation place m
