Specifications
MOQ :
1
Price :
negotiable
Brand Name :
Bestone, Benetech
Model Number :
GT633B
Certification :
CE,ROHS,FCC,ISO
Place of Origin :
CHINA
Payment Terms :
T/T,Western Union,MoneyGram
Supply Ability :
more than 1000pcs per month
Delivery Time :
5-8 working days
Packaging Details :
Aluminum box, colored paper box
Measure Range :
0.1~199.9m/S2
Velocity :
0.1~199.9mm/S
Displacement :
0.001~1.999 mm (P-P)
Accuracy :
±5% +2digits
Transport Package :
Gift Box and Carrying Case
Specification :
CE, ROHS
Trademark :
BESTONE, BENETECH
Origin :
China
HS Code :
9031809090
Production Capacity :
100000 Pieces/Year
Description
GT633B Handheld Vibration Meter Tester & Analyzing Instrument
This professional vibration meter utilizes piezoelectric effect technology with artificial polarized ceramic design. Ideal for monitoring various vibrating mechanical equipment, particularly for vibration measurement of rotating and reciprocating machinery. Measures acceleration, velocity, and displacement, making it widely applicable in mechanical manufacturing, electric power metallurgy, and general aviation industries.
Key Features
  1. Measures vibration acceleration, velocity, distance, and temperature
  2. Acceleration measurement with high/low frequency selection
  3. Includes machine level selection feature
  4. Maximum mode capability
  5. Data HOLD function
  6. LCD backlight (steady on)
  7. Automatic/manual shutdown options
  8. Temperature unit selection
  9. Measurement unit selection
  10. Lithium battery powered with USB charging
Technical Specifications
Model GT633B
Parameter Range Accuracy/Notes
Acceleration 0.1~199.9m/s² peak ±5%±2digits (10Hz~1KHz LO, 1KHz~3KHz HI)
Velocity 0.1~199.9mm/s rms 10Hz~1KHz (LO)
Distance 0.001~1.999mm p-p 10Hz~1KHz (LO)
Operating temperature 0-40ºC(32-104ºF) ±1.5ºC(±2.7°F)
Operating humidity 30-90%RH
Vibration pickup Piezoelectric ceramic accelerometer (shear-type)
Displays update cycle About 0.5 seconds
Power 1000mAh 3.7V lithium battery
Stand-by current ≤15μA
Operating current ≤25mA
Battery life 20H continuous use
Product Images
GT633B Handheld Vibration Meter with 1000mAh Lithium Battery Piezoelectric Ceramic Accelerometer and CE ROHS Certification GT633B Handheld Vibration Meter with 1000mAh Lithium Battery Piezoelectric Ceramic Accelerometer and CE ROHS Certification GT633B Handheld Vibration Meter with 1000mAh Lithium Battery Piezoelectric Ceramic Accelerometer and CE ROHS Certification GT633B Handheld Vibration Meter with 1000mAh Lithium Battery Piezoelectric Ceramic Accelerometer and CE ROHS Certification GT633B Handheld Vibration Meter with 1000mAh Lithium Battery Piezoelectric Ceramic Accelerometer and CE ROHS Certification
