Round Square T-Bar HDG Cable Ladder Type U For Main Power Feeder Routing
Round Square T-Bar HDG Cable Ladder Type U For Main Power Feeder Routing
Round Square T-Bar HDG Cable Ladder Type U For Main Power Feeder Routing
Round Square T-Bar HDG Cable Ladder Type U For Main Power Feeder Routing
Round Square T-Bar HDG Cable Ladder Type U For Main Power Feeder Routing
Round Square T-Bar HDG Cable Ladder Type U For Main Power Feeder Routing
Specifications
Brand Name :
BDINDUSTRIAL
Model Number :
Cable Ladder Type U
Certification :
IEC 61537，BS EN 61537,NEMA/CSA
Place of Origin :
CHINA
MOQ :
100 m
Price :
10-20 USD
Payment Terms :
L/C,D/P,T/T
Supply Ability :
50000m/week
Delivery Time :
15-25 work days
Packaging Details :
Carton, Box, Wooden carton
Product Name :
Cable Ladder,Type U
Keywords :
U‑shaped cable ladder
Material :
Carbon Steel,Stainless Steel,Aluminum
Height :
75-250 mm/3-10 in（customize）
Width :
150-900 mm/6-36 in（customize)
Thickness :
Side Rail: 1.5-3.0 mm; Rung: 2.5-5.0 mm
Rung Spacing :
225 mm, 300 mm, 450 mm（customize)
Support Span :
1.5-9 m
Description

Cable Ladder Type U

The Bending Cable Ladder Type U offers excellent load-bearing capacity, making it suitable for long-span installations and heavy cable loads.Cables can be installed or removed from the top or side with great ease. The open structure simplifies inspection, modifications, and future expansions.

Round Square T-Bar HDG Cable Ladder Type U For Main Power Feeder Routing

Round Square T-Bar HDG Cable Ladder Type U For Main Power Feeder Routing

Round Square T-Bar HDG Cable Ladder Type U For Main Power Feeder Routing

Common Specifications

The specific specifications of the Bending Cable Ladder Type U depend on the project.

Material Pre-galvanized Steel (PG), Hot-Dip Galvanized Steel (HDG), Stainless Steel (SS 304/316), Aluminum Alloy
Ladder Width

150mm (6"),300mm (12"), 450mm (18"), 600mm (24"), 750mm (30"), 900mm (36")
Side Rail Height

75mm(3"),100mm(4"),150mm (6"),200mm(8"),250mm(10")
Rung Spacing 225 mm, 300 mm, 450 mm
Rung Shape/Type Round, Square, "T-Bar"
Maximum Support Span 1.5m, 3m, 4.5m, 6m, 9m
Accessories Horizontal Bends (30°, 45°, 90°), Vertical Bends, Reducers, Crosses, Tees.
Support Methods Center Hung (Rod & Clamp), Wall Mounted (Cantilever Brackets), Underfloor

Typical Applications

Widely used for main power feeder routing, heavy industrial cable management, data center backbone cabling, outdoor/harsh‑environment installations, and long‑span cable bridging in infrastructure projects.

Advantages

1. Direct from the factory

2. Easy to install

3. Competitive pricing

4. Guaranteed quality

5. 24-hour after-sales service

We always have ample stock of materials to meet your urgent needs. After placing an order, we will send you the exact delivery time and production schedule.
