NCM811 Cathode Material MS-811-83 Single Crystal Lithium Niobate Coated
NCM811 Cathode Material MS-811-83 Single Crystal Lithium Niobate Coated
NCM811 Cathode Material MS-811-83 Single Crystal Lithium Niobate Coated
NCM811 Cathode Material MS-811-83 Single Crystal Lithium Niobate Coated
Specifications
Brand Name :
XWELL
Model Number :
MS-811-83
Place of Origin :
China
MOQ :
5g
Price :
10-10000USD/Negotiable
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability :
1000g/month
Delivery Time :
5-8 working days
Packaging Details :
bottle
Product Usage :
Laboratory
Calendering Density :
3.53g/cm³
SSA (BET) :
0.58m²/g
Element Content :
82.1%
Application :
Solid-state battery
Description
NCM811 Cathode Material MS-811-83 Single Crystal Lithium Niobate Coated for Solid-state battery Applications

Advanced high-voltage, high-capacity cathode material designed for scientific research applications, compatible with silicon-carbon anodes for high-capacity battery cell production.

Key Specifications
Item Sub-item Unit Value Instrument
Particle Size D10 μm 2.1 Malvern Instruments Ltd MASTERSIZER2000
D50 μm 3.9
D90 μm 7
Calendering Density g/cm³ 3.53 Micromeritics GeoPyc 1360
SSA (BET) m²/g 0.58 Micromeritics Tristar 3000
Element Content % 82.1 METTLER TOLEDO FE30
Co % 12 METTLER TOLEDO G20
Mn % 5.9
Li₂CO₃ % 1130
LiOH % 1730
Liquid Battery Data
EC/DMC/EMC = 1:1:1 with 1.1mol/L LiPF₆, 1.5% VC and 1.5% PS		 Parameter Rate Value
Liquid Battery Data
EC/DMC/EMC = 1:1:1 with 1.1mol/L LiPF₆, 1.5% VC and 1.5% PS		 Capacity 0.1C 210 mAh/g
Capacity 0.5C 199 mAh/g
Capacity 1C 193.5 mAh/g
Efficiency 0.1C 92.40%
All-Solid-State Battery Data
Composite Cathode Ratio: 7:3
Anode: Lithium-Indium Alloy		 Parameter Rate Value
All-Solid-State Battery Data
Composite Cathode Ratio: 7:3
Anode: Lithium-Indium Alloy		 Capacity 0.1C Ch 248.6 mAh/g
Capacity 0.1C Disc 200 mAh/g
Efficiency 0.1C 80%
SEM picture
NCM811 Cathode Material MS-811-83 Single Crystal Lithium Niobate Coated
NCM811 Cathode Material MS-811-83 Single Crystal Lithium Niobate Coated
Product Advantages
  • Enhanced Battery Life: Minimizes delamination risks during charge cycles
  • Process Compatibility: Optimized for slurry coating, calendering, and stacking processes
  • Quality Consistency: Strict ±1μm tolerance control ensures reliable industrial-scale production
