30KW Tethered DC 48 Amp EV Charger For Electric Car
30KW Tethered DC 48 Amp EV Charger For Electric Car
30KW Tethered DC 48 Amp EV Charger For Electric Car
30KW Tethered DC 48 Amp EV Charger For Electric Car
Specifications
Brand Name :
SYEV
Model Number :
EVP30
Certification :
CCC
Place of Origin :
Xiamen, China
MOQ :
1unit
Price :
USD35000~55000/unit
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
1000units/month
Delivery Time :
25days
Packaging Details :
Naked
Charger Type :
DC Charger, FAST Charger
Input Voltage :
400V+10%
Output Voltage :
200-1000Vdc
Seats Number :
11-14 passengers
Input Current :
45A
Maxium Output Powe :
30KW
Weight :
35.3kg
Description

30KW EV Car DC Charger Electric Car Charger Applied For Charging Stations

Techanical Ratings
AC Input
Connection type U/V/W+N+PE
Input voltage 400V±10%
Input frequency 50Hz/60Hz±10%
Rated power 30kW
Max input current 45A
Power factor ≥0.98, Maximum value
THDi <5%, Best case
Max. efficiency >94%
DC Output
Charging interface Port A: CCS2 Port B: CCS2, IEC 62196-3, DIN70121
Communication with EV DIN 70121, ISO 15118
Output voltage range 200-1000Vdc
DC Output - When both guns are used for charging at the same time
Maximum output current 75A , each gun
Rated output voltage1 400Vdc
DC output 一 When only single gun is used
Maximum output current 750A
Maximum output power* 30kW
HMI
Touch screen 8-inch touch screen
RFID2 IEC/ISO14443A/B, Mifare/Felica optional
Payment terminal Nayax VPOS touch
Network 4G modem, Ethernet port *1
Protocol for backend3 OCPP 1.6J
Ambient Conditions
Operating temp, range -10°C~+50°C
Operating humidity 5-95%
Operating altitude ≤2000m
Mechanical Data
Dimension (W*D*nf 707*560*217mm
Degree of protection IP54
Cooling method Force air cooling
Charging cable length 5.0m
Noise level ≤75dB
Weight 35.3kg
Standard and Compliance
Standard IEC 61851-1, IEC 61851-23, IEC 61851-24, IEC 62619-3
IEC 61851-21-2, IEC 61800-2, IEC 61800-4
Certification mark TUV CE
