A SE4430 Scanning Machine Mrz Ocr Passport Reader Barcode Scanner Module
A SE4430 Scanning Machine Mrz Ocr Passport Reader Barcode Scanner Module
A SE4430 Scanning Machine Mrz Ocr Passport Reader Barcode Scanner Module
A SE4430 Scanning Machine Mrz Ocr Passport Reader Barcode Scanner Module
A SE4430 Scanning Machine Mrz Ocr Passport Reader Barcode Scanner Module
A SE4430 Scanning Machine Mrz Ocr Passport Reader Barcode Scanner Module
A SE4430 Scanning Machine Mrz Ocr Passport Reader Barcode Scanner Module
A SE4430 Scanning Machine Mrz Ocr Passport Reader Barcode Scanner Module
A SE4430 Scanning Machine Mrz Ocr Passport Reader Barcode Scanner Module
A SE4430 Scanning Machine Mrz Ocr Passport Reader Barcode Scanner Module
A SE4430 Scanning Machine Mrz Ocr Passport Reader Barcode Scanner Module
A SE4430 Scanning Machine Mrz Ocr Passport Reader Barcode Scanner Module
A SE4430 Scanning Machine Mrz Ocr Passport Reader Barcode Scanner Module
A SE4430 Scanning Machine Mrz Ocr Passport Reader Barcode Scanner Module
Specifications
private mold :
Yes
products status :
Stock
type :
Barcode Scanner
scan element type :
CMOS
colour depth :
32 Bit
interface type :
usb
max paper size :
A4 Size
Brand Name :
WCMI
Place of Origin :
Tianjin, China
warranty(year) :
15 months
after-sales service :
Return and Replacement, Others, Repair, Free spare parts, Onsite Training and Inspection, Call Center and on-line Technical Support
software development kit (sdk) :
NO
color :
Black
sensor :
CMOS 640*480
Light source :
White LED
View Angle :
Horizontal 37°, Vertical 28°
Scan Angle :
Rotation: 360°, Pitch: 60°, Deflection: 60°
Scan Mode :
Induction mode,continous mode,manual mode,command-triggered mode
Precisions :
1d ≥5mil / 2d ≥10mil
Symbol Contrast :
≥20%
Weight :
<7g
Dimension :
26mm x 22mm x 12mm
Description
Product Description
A SE4430 Scanning Machine Mrz Ocr Passport Reader Barcode Scanner Module
A SE4430 Scanning Machine Mrz Ocr Passport Reader Barcode Scanner Module
A SE4430 Scanning Machine Mrz Ocr Passport Reader Barcode Scanner Module
A SE4430 Scanning Machine Mrz Ocr Passport Reader Barcode Scanner Module
Specification
Product Parameters










General
Type
Barcode Scanner Module
Product model
SE4330
Brand Name
WCMI
Product Specification
Barcode Scanner Module
Products Status
Stock
Place of Origin
Tianjin,China
Private Model
Yes
Warranty(Year)
2yeras
After-sales Service
Return and Replacement; Free spare parts
Certification
RoHS FCC CE
Color
white
Language Supported
English/Customized
Scan Element Type
CMOS











Scan Code Performance
Image (Pixels) Sensor
640x480 CMOS
Light Source
White LED
View Angle
Horizontal37°,Vertical28°



Decoding capability
2D:QR 、PDF417、DataMatrix（ECC200）、Aztec、HANXIN code、Maxicode、Micro QR、Micro PDF417 1D:EAN13、EAN8、UPC-A、UPC-E0、UPC-E1、Code128、
Code93、CodaBar、Interleaved 2 of 5、Industrial 2 of 5、Matrix 2 of 5、Code11、 MSI-Plessey、Standard 2 of 5、Plessey、China Post、
Code16K、Code 49、GS1 Databar(RSS-Expand, RSS-Limited, RSS-14)
Depth of Field
EAN-13 40~285mm （13mil）
Code39 35~140mm （5mil ）
QR Code 25~185mm (15mil)
Scan Angle
Rotation: 360°, Pitch± 45°, Deflection±45°

Scan Speed
More than 48 times/sec
Precisions
1d ≥4mil / 2d ≥10mil
Motion Tolerance
More than 48 times/sec
Symbol Contrast
≥20%



Physical Parameters
Weight
<7g
Dimensions
26mm x 22mm x12mm

Interface
TTL-232 /VCP /USB-HID_keyboard / USB-HID_POS
Sleep Current
< 130 mA
Work Current
< 230 mA
Voltage
DC +3.3V ~ +5V (±5%)



Environmental Parameter
Operating temperature
-20℃ ~ 60℃
Storage temperature
-40℃ ~ 70℃
ESD Protection
Contact Discharge ±6KV, Air Discharge ±10KV
Shock
5~200Hz，10Grms，3axes，1.5Hr
Operating Humidity
5%RH~95%RH (Non-condensing)
Company Information
A SE4430 Scanning Machine Mrz Ocr Passport Reader Barcode Scanner Module
A SE4430 Scanning Machine Mrz Ocr Passport Reader Barcode Scanner Module
A SE4430 Scanning Machine Mrz Ocr Passport Reader Barcode Scanner Module
Tianjin wavecreating Micro Intelligennt Technology CO., Ltd. is one of the leading professional R&D manufacturers for barcode scanning products in China. Our company is located in Tianjin Economic and Technological Development Area and has a registered capital of 10 million yuan. The company continuously insist on defining products from the chip, taking customized chips, image recognition algorithms and customized services as our core competency and consistently strive to improve it. The company has more than 50 employees, including 36 R&D staff, 97% of whom have a bachelor’s degree or above, 9 masters, and 2 doctors.
Packing & Delivery
A SE4430 Scanning Machine Mrz Ocr Passport Reader Barcode Scanner Module
A SE4430 Scanning Machine Mrz Ocr Passport Reader Barcode Scanner Module
Certification
A SE4430 Scanning Machine Mrz Ocr Passport Reader Barcode Scanner Module
FAQ
1. Is OEM or ODM available?
Yes. We are the factory directly. We can make it as your requirement.
2. What’s the warranty policy for the barcode scanners?
We provide 24 months maintenance warranties. During warranty, free and quick advice for repairing, free spare parts if it is
necessary for replacement or new barcode scanners replacement in the next order.
3. Why so competitive?
We have a professional R & D team and technical team and have a large domestic market. So large quantity will reduce our raw material cost directly. What's more, we have mature technology to save costs.
4. How to control the performance stability?
We take the flow line production in the whole processing. Every product will test 4 times at least before it is delivered.
5. How about the factory?
We have more than 200 workers with an advanced dust-free plant. We are approved the new high-tech enterprise by the government. Owned many technical and design patents in different professional fields.
