A SE4631 Barcode Reader Qr Code Scanner Qr Reader Mrz Ocr Scanners Reader Module

Specifications

private mold :

Yes

products status :

Stock

type :

Barcode Scanner

scan element type :

CMOS

colour depth :

32 Bit

interface type :

usb

max paper size :

A4 Size

optical resolution :

640-480

scan speed :

60-100

Brand Name :

WCMI

Place of Origin :

Tianjin, China

warranty(year) :

15 months

after-sales service :

Return and Replacement, Others, Repair, Free spare parts, Onsite Training and Inspection, Call Center and on-line Technical Support

software development kit (sdk) :

Yes

color :

Black

sensor :

CMOS 640*480

Light source :

White LED

View Angle :

Horizontal 37°

Scan Angle :

Rotation: 360°, Pitch: 60°, Deflection: 60°

Scan Mode :

Induction mode,continous mode,manual mode,command-triggered mode

Precisions :

1d ≥5mil / 2d ≥10mil

Symbol Contrast :

≥20%

Weight :

<10g

Dimension :

26.15mm x 12.09mm x 13.85mm

Description

Product Description

Product Parameters
General	Type	barcode scanner engine
		Product model	SE4631
		Brand Name	WCMI
		Product Specification	Mini Barcode Scanner Engine
		Products Status	Stock
		Place of Origin	Tianjin,China
		Private Model	Yes
		Warranty(Year)	2-year
		After-sales Service	Return and Replacement; Free spare parts
		Certification	RoHS、CE、FCC
		Color	black
		Language Supported	English/Customized
		Scan Element Type	CMOS
Scan code Performance	Image (Pixels) Sensor	640 X 480 CMOS @ 30fps
		Light Source	White LED
		View Angle	Horizontal 37°
		Decoding Capability	2D: QR 、PDF417、DataMatrix（ECC200）、Aztec、HANXIN code、Maxicode、Micro QR、Micro PDF417 1D: EAN13、EAN8、UPC-A、UPC-E0、UPC-E1、 Code128、Code39、Code93、CodaBar、Interleaved 2 of 5、Industrial 2 of 5、Matrix 2 of 5、Code11、 MSI- Plessey、Standard 2 of 5、Plessey、China Post、Code 16K、GS1 Databar(RSS-Expand, RSS-Limited, RSS-14)
		Depth of Field	EAN13: 40~200 mm （13mil） CODE128: 45~250 mm （15mil） QR: 40-180mm(15mil)
		Scan Angle	Rotation: 360°, Pitch: ±60°, Deflection: ± 60°
		Scan Mode	Continuous mode, Induction mode, Manual mode, Command-Triggered Mode
		Precisions	1d ≥5mil / 2d ≥10mil
		Symbol Contrast	≥15%
Physical Parameters	Weight	<10g
		Dimensions	26.15mm x 12.09mm x 13.85mm
		Interface	TTL-232 / USB 2.0 Full Speed
		Prompt Mode	LED prompt and buzzer (external connection available)
		Voltage	+3.3VDC±5%
		Current	working: 120mA; Sleeping: 500uA
Environmental Parameter	Operating Temperature	-20℃ ~ 60℃
		Storage Temperature	-40℃ ~ 70℃
		Operating Humidity	5%RH~95%RH (Non-condensing)

Company Information

Tianjin wavecreating Micro Intelligennt Technology CO., Ltd. is one of the leading professional R&D manufacturers for barcode scanning products in China. Our company is located in Tianjin Economic and Technological Development Area and has a registered capital of 10 million yuan. The company continuously insist on defining products from the chip, taking customized chips, image recognition algorithms and customized services as our core competency and consistently strive to improve it. The company has more than 50 employees, including 36 R&D staff, 97% of whom have a bachelor’s degree or above, 9 masters, and 2 doctors.

Packing & Delivery

Certification

FAQ

1. Is OEM or ODM available?

Yes. We are the factory directly. We can make it as your requirement.
2. What’s the warranty policy for the barcode scanners?
We provide 24 months maintenance warranties. During warranty, free and quick advice for repairing, free spare parts if it is
necessary for replacement or new barcode scanners replacement in the next order.
3. Why so competitive?
We have a professional R & D team and technical team and have a large domestic market. So large quantity will reduce our raw material cost directly. What's more, we have mature technology to save costs.
4. How to control the performance stability?
We take the flow line production in the whole processing. Every product will test 4 times at least before it is delivered.
5. How about the factory?
We have more than 200 workers with an advanced dust-free plant. We are approved the new high-tech enterprise by the government. Owned many technical and design patents in different professional fields.
