High Distribution Precision Stator Needle Winding Machine With Dual Stations
High Distribution Precision Stator Needle Winding Machine With Dual Stations
High Distribution Precision Stator Needle Winding Machine With Dual Stations
High Distribution Precision Stator Needle Winding Machine With Dual Stations
High Distribution Precision Stator Needle Winding Machine With Dual Stations
High Distribution Precision Stator Needle Winding Machine With Dual Stations
Specifications
Brand Name :
XINGTE
Model Number :
XT-02D
Certification :
CE,IOS9001,KC,ISO45001,ISO24001
Place of Origin :
CHINA
MOQ :
1
Price :
negotiable
Payment Terms :
L/C, T/T, D/A, D/P
Supply Ability :
2.000 sets per year
Delivery Time :
30-40 working days
Packaging Details :
Wooden case
Application :
AC Brushless Motors, DC Brushed Motors, and DC Brushless Motors
Weight :
600KGS
Dimensions :
(L)1500 *(W)680*(H)1990 mm
After-sales service provided :
engineers available to service machinery overseas, Online Video technical support
Voltage :
380v 50/60HZ
Name :
Dual Stations stator Needle Winding Machine
Warranty :
12 Month
Function :
Stator needle Winding
Winding speed :
Max.1200 RPM
Description
High Distribution Precision Stator Needle Winding Machine With Dual Stations
Product Introduction

The XT-02D High Distribution Precision Dual Station Needle Winding Machine is designed for inverter brushless motor manufacturing. Utilizing double-station needle winding technology, this machine is primarily used for multi-pole stator winding applications.

Features include manual feeding, automatic clamping die, multiple taps (screen setting), wire clamping, and wire cutting during the winding process. Each action cycle wraps 2 stators simultaneously, significantly improving production efficiency and reducing labor intensity.

Operation is controlled through a user-friendly interface with PLC, display, and servo motor control for safe and reliable performance.

Applications

This automatic motor winding machine is particularly suitable for:

  • Inverter washing machine motors
  • Inverter cleaner motors
  • Other BLDC/brushless motors
Function and Characteristics
Multi-Pole Winding Capability

Designed for multi-pole BLDC motor stator winding with manual loading/unloading and automatic clamping, winding, and shearing.

Stable Construction

Frame constructed with thickened aluminum profile and cast iron table plate to absorb vibration, ensuring minimal vibration at high winding speeds.

Reliable Tooling

Tooling and fixture parts utilize downward positioning mode for stable and reliable tightening.

Efficient Wire Management

Compact wire clamping and cutting structure allows for simultaneous wire clamping and cutting operations.

Quick Change-Over

Enables rapid adjustment of stator and winding parameters through HMI to adapt to different stator requirements.

Advanced Control

PLC control with fault display and double station high-speed needle winding capability.

Winding Technology

The stator remains stationary during winding. All needle movements are motorized and programmable, managed in direct drive mode (no cam system, no belts, no lead screw).

High Distribution Precision Stator Needle Winding Machine With Dual Stations High Distribution Precision Stator Needle Winding Machine With Dual Stations

Capable of winding:

  • Inner straight slot stators
  • Inner skewed slot stators
  • Outer stators straight and skewed slot
Product Parameters
Model number XT-02D
Wire Diameter 0.1 ~ Ø1.6mm
Stator Outer diameter Max 106mm
Stator inner diameter 10mm
Stator stack thickness 150mm
Winding method needle winding
Winding station 2 stations
Power 6KW
Power supply AC380V,50/60Hz
Air pressure > 0.6Mpa
Winding speed 1200Rpm
Machine dimension (L)1500 *(W)680*(H)1990 mm
G. W 600KGS
Applicable Industries

Suitable for manufacturers of household appliances including washing machines, fan motors, ceiling fan motors, hub motors, vacuum cleaners, mixers, hair dryers, cameras, and household electric fans.

About XINGTE
Experience

Established in 2007 with over 17 years R&D experience in coil winding technology

Plant Size

Headquartered in Shenzhen with factory area over 30,000 square meters ensuring strong productivity

Service

Over 230 technical service and after-sales staff with worldwide service points

Patents & Certificates

120+ Patents and related certificates obtained

Production Capacity

Over 600 experienced employees ensuring production capacity and fast delivery

Technology

Over 130 experienced engineers ensuring strong R&D and customization capability

Our Facility
High Distribution Precision Stator Needle Winding Machine With Dual Stations
Machine Gallery
High Distribution Precision Stator Needle Winding Machine With Dual Stations High Distribution Precision Stator Needle Winding Machine With Dual Stations High Distribution Precision Stator Needle Winding Machine With Dual Stations
Stator Coil Samples
High Distribution Precision Stator Needle Winding Machine With Dual Stations
Order Process
High Distribution Precision Stator Needle Winding Machine With Dual Stations
Delivery
High Distribution Precision Stator Needle Winding Machine With Dual Stations
Our Partners
High Distribution Precision Stator Needle Winding Machine With Dual Stations
