High Efficiency Automatic Voice Coil Winding Machine With PLC Touch Screen
High Efficiency Automatic Voice Coil Winding Machine With PLC Touch Screen
High Efficiency Automatic Voice Coil Winding Machine With PLC Touch Screen
High Efficiency Automatic Voice Coil Winding Machine With PLC Touch Screen
High Efficiency Automatic Voice Coil Winding Machine With PLC Touch Screen
High Efficiency Automatic Voice Coil Winding Machine With PLC Touch Screen
High Efficiency Automatic Voice Coil Winding Machine With PLC Touch Screen
High Efficiency Automatic Voice Coil Winding Machine With PLC Touch Screen
Specifications
Brand Name :
XINGTE
Model Number :
XT-601SD
Place of Origin :
CHINA
Certification :
CE,IOS9001,KC,ISO45001,ISO24001
MOQ :
1
Price :
Negotiate
Packaging Details :
Wooden case
Delivery Time :
15-25 days
Payment Terms :
LC,T/T
Supply Ability :
1500PCS/MONTH
yield rate :
＞90%
coil Diameter Range :
10mm-200mm
capacity :
500pcs/H
coil curing method :
Preheat The Fixture To Dry
Product Type :
Automatic Winding Machine
Control System :
PLC Touch Screen
Power Supply :
220V/50Hz
Application :
RFID Coils. Laser Heads, Voice Coils, Magnet Coils, Sensor Coils, Vibrator Coils And Pancake Motor Coils
Description
High Efficiency Automatic Voice Coil Winding Machine With PLC Touch Screen
Product Overview
Maximize your production with the XT-601SD Automatic Air Coil Winding Machine, specially designed for large-diameter wire and coil applications. This standalone fully automatic system is engineered for winding self-supporting air coils using wire coated with thermoplastic adhesive.
The machine utilizes hot air supply to heat the wire during winding, allowing turns to bond together through the adhesive. This process creates extremely durable and strong finished coils that can be easily removed from tooling and automatically ejected from the machine.
Advanced Features
  • High-precision ball screw guide for flawless layer winding
  • Tooling flange position checking with thermal expansion compensation
  • Specialized software for even and uneven turns per layer winding
  • Intermittent wire feed mechanism for perfect layer coil winding
  • New type controller and pul-servo tension system
  • PLC touch screen control system
Technical Specifications
Power Supply 220V/50Hz
Capacity 500pcs/H
Lead Wire Length 50-70mm
Tension Control Automatic Tension Control System
Safety Features Emergency Stop Button, Overload Protection
Wire Diameter Range 0.06mm - 0.8mm
Coil Diameter Range 10mm-200mm
Winding Direction Clockwise/Counterclockwise
Operate Rate >85%
Control System PLC Touch Screen
Applications
XT-601SD is used for various applications including windings for RFID coils, laser heads, voice coils, magnet coils, sensor coils, vibrator coils, and pancake motor coils.
Customization & Ordering
Brand: XINGTE | Model: XT-601SD | Origin: China
Certification: CE, ISO9001, KC, ISO45001, ISO24001
  • Minimum Order Quantity: 1
  • Price: Negotiable
  • Packaging: Wooden case
  • Delivery Time: 15-25 days
  • Payment Terms: LC, T/T
  • Supply Ability: 1500PCS/MONTH
Machine Samples
High Efficiency Automatic Voice Coil Winding Machine With PLC Touch Screen High Efficiency Automatic Voice Coil Winding Machine With PLC Touch Screen
Coil Samples
High Efficiency Automatic Voice Coil Winding Machine With PLC Touch Screen
