Automatic Flow Pouch Pillow Type Soap Tape Packing Machine Horizontal Flow pack Wrap Bag Pillow Packaging Machine
Automatic Flow Pouch Pillow Type Soap Tape Packing Machine Horizontal Flow pack Wrap Bag Pillow Packaging Machine
Specifications
Brand Name :
LTPM CHINA
Model Number :
KD-Series
Certification :
CE, GMP, SGS, BV
Place of Origin :
Zhejiang Province,China
MOQ :
1 set
Price :
Negotiation
Payment Terms :
L/C,D/A,D/P,T/T,MoneyGram
Supply Ability :
45 sets/month
Delivery Time :
25 days
Packaging Details :
Export Standard Wooden Case
Function :
PACKING
Packaging Type :
Stand-up Pouch, BAGS, Film, FOIL, Pouch
Voltage :
220V,50/60HZ.2.4kw-4kw
Packing Range :
10-1000g
Packing accuracy :
0.1-1.0g
Dimension :
(L)4020*(W)720*(H)1320mm
Weight :
750kg
Description

Products Description

The fully automatic pillow packaging machine is a packaging equipment that can automatically and continuously make bags, seal and cut. It can realize the rapid bag making and packaging of products, and seal and cut products into independent packages in sections. The servo motor transmission speed is stable and adjustable, and the adjustment range is wide; the original roller self-rotation device can continuously seal and cut. It is designed for the packaging of solid objects, suitable for packaging various solid regular objects, such as biscuits, bread, moon cakes, candies, etc., as well as daily necessities, industrial parts, etc. For loose objects or individual separated objects, the packaged objects must be placed in a box first, or tied together, and then bag making, sealing and cutting can be carried out. It can quickly and efficiently complete the bagging, sealing and cutting of products with single-layer film plastic stretched into long bags.



Features


‌1. High degree of automation‌: The pillow packaging machine adopts advanced automation technology, which can realize a series of operations such as automatic feeding, packaging, sealing, and printing production date, greatly improving production efficiency.

‌2. Good packaging quality‌: The use of high-precision mechanical components and advanced sealing technology can ensure the quality of packaging and sealing, and effectively prevent the product from being contaminated during transportation and storage.

‌3. Wide range of applications‌: It is suitable for packaging of various shapes and specifications, such as granular, flake,strip, etc., and can be customized according to different product requirements.

‌4. Easy to operate‌: It adopts human-machine interface design, which is simple and easy to understand, convenient and fast. At the same time, it is equipped with a fault prompt function, which can timely discover and solve equipment failure problems. ‌

5 Energy saving and environmental protection‌:The use of advanced energy-saving technology can effectively reduce energy consumption and environmental pollution, which is in line with the current era of green environmental protection. ‌6.High reliability‌: It adopts high-quality materials and strict production processes, has high stability and reliability, and can ensure long-term stable operation

Main Technical Parameter

Maximum film width(mm)
260-800mm
Manufacturing bag length(mm)
65-no limit
Product height(mm)
55-100mm
Roll film diameter(mm)
Max.320mm
Manufacturing bag width(mm)
30-380mm
Packaging speed(piece/min)
30-230pieces/min
Power specifications
220V,50/60HZ.2.4kw-4kw
Additional configurations can be added
Coding, inflation, punching
Packaging material
Single-layer heat-sealed packaging material (such as bopp, cpp, opp-cpp, opp-pe film, etc.)
Sealing pattern
Stripe + serration, mesh + serration, mesh + easy-tear design



Application
