Vending Machine 5V DC Industrial Keypad 97.5×116mm ATM Pin Keypad
Vending Machine 5V DC Industrial Keypad 97.5×116mm ATM Pin Keypad
Specifications
Place of Origin :
China
Brand Name :
KMY
Certification :
CE,ROHS,FCC
Model Number :
KMY3502E
MOQ :
50
Price :
It depends on quantity
Packaging Details :
High quality carton with customized foam inside
Delivery Time :
Within 3 working days for sample(US layout)
Payment Terms :
T/T.west union
Supply Ability :
3000pcs per month
Description

Industrial 16 Keys Kiosk Metal Keyboards Customize Metal Keypad For Vending Machine

Faceplate Dimensions(W×H):97.5×116mm (see drawing as below)

Industrial 16 Keys Kiosk Metal Keyboards Customize Metal Keypad For Vending Machine

KMY3502E is a stainless steel keypad with both numeric and function keys .

The layout could be any language and function keys could be customized .

rear mounting installation .

Application

Ø Check-in Kiosk

Ø Boarding Kiosk

Ø Info-Kiosk

Ø Internet Kiosk

Ø Medical Kiosk

Ø Industrial control platform

Ø Gaming machine

Ø Access control platform

Physical Features

Ø Keypad made of high quality stainless steel

Ø Customizable layout, dimension and installation design

Ø Dustproof, waterproof, shake-proof, pickproof, drill-proof, bombproof

Ø Ports for optional eight external function keys, beeper and guide light

Ø IP Protection Class IEC/DIN/EN/ 60529:IP65

Ø IK Protection Class DIN EN 50102:IK07

Ø GW: 0.5KG

Reliability and Performance Data

Ø Key lifetime > 2,000,000 cycles per key

Ø Force on keys: 3~5 N

Ø Key travel: 0.45mm

Ø Wide voltage input: 5V DC +/- 20%

Ø In running state, 5 V +/- 20% is needed; the electrical current is up to 100 mA and the actual power consumption is below 1.5W.

Ø Running lifetime > 5 years; Battery lifetime > 5 years (without external power supply)

Environment Requirements

Ø Only the front panels shall be exposed to outdoor climate. The panels are dustproof, waterproof, shake-proof, pickproof, drill-proof and bombproof.

Ø Operating temperature range: 0℃‑ 45℃

Ø Storage temperature range: –25℃ - 65℃

Ø Maximum humidity in operating environment: 80%

Vending Machine 5V DC Industrial Keypad 97.5×116mm ATM Pin Keypad
