Specifications
Brand Name :
YGT
Model Number :
UHT-JUICE
Certification :
CE
Place of Origin :
CHINA
MOQ :
1 sets
Price :
CUSTOM MADE
Payment Terms :
L/C, T/T
Supply Ability :
10 SETS PER MONTH
Delivery Time :
45 WORKING DAYS
Packaging Details :
export standard
Name :
UHT sterilizer
Application :
for dairy milk, tea drink, coconut milk etc
Material :
SUS304 /SUS316L
Capacity :
500kgs/H-20T/H
Heat Energy :
by steam
Advantage :
energy save
Description

Dairy Coconut Milk / Cow Milk Drink UHT Sterilization Machine With Energy Save

Applicable range

The tubular sterilizer is featured by wide and accurate sterilizing temperature and wide application range.It is suitable for various fruit juices and beverages,especially for pulp beverages containing high fiber,such as pineapple,carrot,peach,pear,beverages,such as peanut milk,yoghurt and tea beverage etc.The sterilizing effect is more obvious for fruit paste with high viscosity and weak fluidity.

Working Principle:

Tubular heat exchanger,materials as well as heat exchange medium all the state of turbulence to create high heat exchanging rate,reduce the formation of scaling,and therefore,lengthen the continuous working time of sterilization equipment.

Technology Data

Fruit Juice UHT Tube Sterilizer Machine
Main technical parameters
Type

Capacity

(t/h)

Steam consumption

(kg/h)

Steam pressure

(kg)

Power

(kw)

Dimension

l*h*d(m)

Weight

(kg)

 Diameter(mm)
material steam medium
YGT0.25C-GZ-5MJ 5 430 4.0 3.7 2.0*1.6*2.0 1120 38 DN50 38
YGT0.25C-GZ-15MJ 15 1290 4.0 7.0 2.5*2.5*2.2 2020 63 DN80 63
YGT0.25C-GZ-20MJ 20 1720 4.0 8.0 2.5*2.5*2.2 2220 63 DN80 63
YGT0.25C-GZ-30MJ 30 2580 4.0 11.0 2.5*2.5*2.2 2720 76 DN100 76
YGT0.25C-GZ-50MJ 50 4300 4.0 11.0 2.5*2.5*2.5 3500 101 DN125 101
Process: 35℃→135℃(4s)→40℃ (as per request)

Pre-sale service:

1. Free of making offers, craft and technical guidance.

2. We can provide company’s qualification certification and the drawings.

3. We can also make customized products according to customer’s needs.

After-sale service:

1. We provide long-term after-sale service.

2. Owing to the quotation of our equipment is FOB price which excluded charges of door-to-door service. Thus, if necessary, we can appoint our technician to debug the machine with air ticket, visa, accommodation and labor cost provided by your party. Or you can send your technician to our company to learn techniques.

3. Meanwhile, you can call or e-mail to consult any relevant questions since we have a special line of after-sale service. Or you can communicate online and solve the problems.
