Flat TPS 2 Core PVC Insulated Cable 450 750V
Flat TPS 2 Core PVC Insulated Cable 450 750V
Specifications
Brand Name :
UNI-CABLES
Model Number :
TPS Flat
Certification :
CCC,ISO9001,SAA
Place of Origin :
CHINA
MOQ :
1000 Meters
Price :
Negotiable
Supply Ability :
10000 per Week
Delivery Time :
10 working days
Packaging Details :
100 meters per roll, or 1000 meters per reel
Voltage Rating :
450/750V
Temperature Rating :
90°C
Minimum Bending Radius :
Fixed: 7 x overall diameter Flexed: 10 x overall diameter
Conductor :
Class 2 copper conductor
Insulation :
V90 PVC
Sheath :
3V 90 PVC
Description

Flat TPS 2 Core 3 Core and Earth PVC Insulated Cable Wire Voltage 450/750V

Application

These cables are used for general wiring, unenclosed, enclosed in conduit, buried direct or in underground ducts for domestic, commercial and industrial installations where not subject to mechanical damage. Suitable for balanced three phase applications with E.

Cable Standard

AS/NZS 5000.2,
AS 1125, AS 3808

Cable Construction

Conductor: Plain annealed copper
Maximum continuous operating temperature: 90°C


Insulation: V-90 PVC

Colours:Red, White, Blue, Green/yellow

Sheath: 3V-90 PVC
Colours: White, other colors are available upon request

Technical Characteristics

Conductor Nominal Area
mm2		 Current Ratings Electrical Characteristics
Unenclosed In Air
A		 Surrounded by thermal insulation A Buried In Ducts
A		 Maximum DC Resistance
@20°C
Ohm/km		 Maximum AC Resistance
@75°C
Ohm/km		 Reactance Ohm/km
1 16 8 19 18.1 27.0 0.119
1.5 21 10 24 13.6 17.3 0.111
2.5 30 15 34 7.41 9.45 0.102
4 39 19 44 4.61 5.88 0.102
6 50 25 56 3.08 3.93 0.0967
10 68 34 75 1.83 2.33 0.0906
16 91 46 97 1.15 1.47 0.0861


Cable Parameter

2 Cores and Earth

Nom.
conductor area mm2		 Conductor No./ OD Nom.
insulation thickness mm		 earth
conductor area mm2		 Nom. sheath thickness mm Nom. overall diameter
mm		 Approx. mass kg/km
Min Max
1.0 1/1.13 0.6 1.0 0.9 8.8x4.1 9.3x4.4 75
1.5 7/0.50 0.6 1.5 0.9 10.0x4.5 10.0x4.5 95
2.5 7/0.67 0.7 2.5 1 12.1x5.4 12.7x5.7 145
4 7/0.85 0.8 2.5 1.1 13.7x6.3 14.4x6.6 220
6 7/1.04 1.0 2.5 1.1 14.9x6.9 15.6x7.3 290
10 7/1.35 1.0 4 1.2 18.9x8.3 19.0x8.7 440
16 7/1.70 1.0 6 1.3 21.0x9.5 22.0x10.0 645

3 Cores and Earth

Nom.
conductor area mm2		 Conductor No./ OD Nom.
insulation thickness mm		 earth
conductor area mm2		 Nom.
sheath thickness mm		 Nom. overall diameter
mm		 Approx. mass kg/km
Min Max
1.0 1/1.13 0.6 1.0 0.9 11.1x4.1 11.8x4.4 95
1.5 7/0.50 0.6 1.5 0.9 12.6x4.5 13.3x4.8 120
2.5 7/0.67 0.7 2.5 1 15.6x5.4 16.4x5.7 190
4 7/0.85 0.8 2.5 1.1 17.7x6.2 18.6x6.7 290
6 7/1.04 1.0 2.5 1.1 19.5x6.9 20.4x7.3 370
10 7/1.35 1.0 4 1.2 24.0x8.2 24.5x8.7 540
16 7/1.70 1.0 6 1.3 27.8x9.5 29.1x10.0 820
