Light Duty Industrial Pvc Armoured Cable , White Black Copper Armoured Cable
Light Duty Industrial Pvc Armoured Cable , White Black Copper Armoured Cable
Light Duty Industrial Pvc Armoured Cable , White Black Copper Armoured Cable
Light Duty Industrial Pvc Armoured Cable , White Black Copper Armoured Cable
Specifications
Brand Name :
UNI-CABLES
Model Number :
2182Y
Certification :
CCC,ISO9001
Place of Origin :
CHINA
MOQ :
100 Rolls
Price :
Depends on Quantity
Supply Ability :
10000 Rolls per Week
Packaging Details :
100 Meters per Roll
Voltage Rating (Uo/U) :
300/300V
Temperature Rating :
+5°C to +70°C
Minimum Bending Radius :
6x overall diameter
Core Identification :
2 core: Blue Brown 3 core: Blue Brown Green/Yellow
Conductor :
Class 5 flexible copper conductor
Sheath Colour :
White Black
Insulation :
PVC (Polyvinyl Chloride)
Sheath :
PVC (Polyvinyl Chloride)
Description

BS EN 50525-2-11 Standard PVC Electrical Cable Type 218-Y Flexible Cable

Light Duty Industrial Pvc Armoured Cable , White Black Copper Armoured Cable

APPLICATION

Light duty cable for use in domestic premises, kitchens and

offices. For use with light portable appliances such as radios, table lamps and office equipment.

CONSTRUCTION

Conductor

Class 5 flexible copper conductor according to BS EN 60228 (previously BS 6360)

Insulation

PVC (Polyvinyl Chloride) Type TI2 according to BS EN 50363

Sheath

PVC (Polyvinyl Chloride) Type TM2 according to BS EN 50363

CABLE STANDARDS

BS EN 50525-2-11 (previously BS 6500, CENELEC HD21.5),

VDE 281, BS EN/IEC 60332-1-2

DIMENSIONS

UNIQUE PART NO. NO. OF CORES NOMINAL CROSS SECTIONAL AREA NOMINAL THICKNESS OF INSULATION NOMINAL THICKNESS OF SHEATH NOMINAL OVERALL DIAMETER NOMINAL WEIGHT
mm² mm mm mm kg/km
UNRVV2X0.5 2 0.5 0.5 0.6 5.0 37
UNRVV2X0.75 2 0.75 0.5 0.6 5.5 46
UNRVV3X0.5 3 0.5 0.5 0.6 5.3 44
UNRVV3X0.75 3 0.75 0.5 0.6 5.8 55
UNRVV4X0.5 4 0.5 0.5 0.6 5.8 54

Colour Codes

COLOUR Black White
CODE BK WH

CONDUCTORS

Class 5 Flexible Copper Conductors for Single Core and Multi-Core Cables

NOMINAL CROSS SECTIONAL AREA
mm²		 MAXIMUM DIAMETER OF WIRES IN CONDUCTOR
mm		 MAXIMUM RESISTANCE OF CONDUCTOR AT 20ºC
Plain Wires
ohms/km
0.5 0.21 39
0.75 0.21 26

ELECTRICAL CHARACTERISTICS

Current Carrying Capacity and Mass Supportable

NOMINAL CROSS SECTIONAL AREA
mm²		 CURRENT CARRYING CAPACITY MAXIMUM MASS SUPPORTABLE BY TWIN FLEXIBLE CORD
kg
Single-Phase AC
Amps		 Three-Phase AC
Amps
0.5 3 3 2
0.75 6 6 3

Voltage Drop

NOMINAL CROSS SECTIONAL AREA
mm²		 DC OR SINGLE-PHASE AC
mV/A/m		 THREE-PHASE AC
mV/A/m
0.5 93 80
0.75 62 54
