SGS Certification Decorative Powder Coating Max 100μM Coating Thickness
SGS Certification Decorative Powder Coating Max 100μM Coating Thickness
SGS Certification Decorative Powder Coating Max 100μM Coating Thickness
SGS Certification Decorative Powder Coating Max 100μM Coating Thickness
SGS Certification Decorative Powder Coating Max 100μM Coating Thickness
SGS Certification Decorative Powder Coating Max 100μM Coating Thickness
Specifications
Brand Name :
No
Model Number :
E2115
Certification :
SGS
Place of Origin :
Tianjin,China
MOQ :
500kg
Price :
$2.6-4.6/kg
Supply Ability :
1000 tons per month
Packaging Details :
20kg/carton
Material :
Polyester resin
Color :
As customer required
Application :
Valve
Application Method :
Electrostatic spray
Gloss :
high/Low/Matt
state :
powder coating
Description

Valve Special Electrostatic Spray Gun thermosetting Powder Coating

The thickness of valve is thick and uneven, the shape of valve is irregular, therefore it is hard to heat valve. When moved, it occur collision which cause destroying the coating. According to the characteristics of the valve, we develop special powder coating for the valve.

The features of coating:

  1. Excellent adhesion, impact resistance and scratch resistance, the valve under the condition of normal collisions, there will be no damage.
  2. Baking condition: 160℃／15--20min or 180℃／10min, this powder coating is suitable for low temperature curing to improve the effective of painting and save energy.
  3. Specular color, good flow, no tag, good cover for corner, the thickness of coating is 100μm.
  4. Solve the antifoaming problem for cast iron valve.
  5. Supply all kinds of colors and textures according to the customer required.

Specification:

Item Test standard result
Gel time GB/T16995-1997 pass
flow ISO8130-5:1992 pass
Baking condition / 160℃／15--20min or 180℃／10min
Coating appearance / normal
Pencil hardness ISO15184:1998 H
adhesion GB/T9286-1998 0
Impact resistance GB/T1732-1993 pass
flexibility GB/T6742 2
Cupping test GB/T9753 6
Gloss GB/9754 >90°

Substrates Coated:

Cold Rolled/Hot Rolled Steel

Galvanized Steel

Iron Castings

Zinc Castings

Copper/Brass

Magnesium

Aluminum Extrusions and Castings

Rare Earth Magnets (NdFeB)

NiZn Plated Steel

Stainless Steel

Powder Metallurgy Parts

Some Non-Metallics
