High Power Magnetic Windmill Residential Vertical Wind Turbine 24V
High Power Magnetic Windmill Residential Vertical Wind Turbine 24V
Specifications
Rated power :
600W
Payment Terms :
T/T
Packaging Details :
Plywood
MOQ :
1
Place of Origin :
Shenzhen, China
Certification :
CE ISO9001 IEC
Supply Ability :
1000 sets per month
Brand Name :
Honor Eco
Delivery Time :
15 days
Price :
Negotiable
Blade quantity :
7 (3 Darrieusand 4 Savonius)
Model Number :
HECO-600
Noise :
Less than 40dB
Product Name :
Maglev Vertical Axis Wind Turbine
Description


High Power Magnetic Windmill Residential Vertical Wind Turbine 24V



1. Description:


The Maglev Vertical Axis Wind Turbine is a perfrect choice for building wind solar hybrid power systems. This system makes use of wind and solar energy to provide clean electric power to households. It is characterized by energy-saving, high-efficiency, easy-installation and long lifespan. It can be not only made optimal configuration according to local natural resource and user's needs, but also can be upgraded to meet increasing load capacity requirements.



2. Applications:


The 600w Maglev Vertical Axis Wind Turbine unit has 24V and 48V for option. It 's ideal for both of residential and commercial applications as well as off grid and on grid power systems. The unit provides a durable, reliable, and fully customized hybrid solution to Telecoms Base Receiver Station (BTS), Charging Station by Solar and wind and also very suitable for power supply to home.


3. Specifications


Maglev Vertical Axis Wind Turbine Items HECO600
Rated power 600W
Dimension (Height/Diameter) Ø1540mm / 1320mm
Weight 50 kg
Blade material Aluminum Alloy
Blade quantity 7 (3 Darrieusand 4 Savonius)
Swept area ㎡ 0.30
Min starting wind speed 1.3 m/s
Cut-in wind speed 3.5m/s
Rated wind speed 13m/s
Cut-off wind speed 15m/s
Survival wind speed 60m/s
Generator type AC,3Phases
Controller Output Voltage 24V/48V
Controller Braking System 3-phase short circuit by NFB brake
Ambient Temperature -40～50 ℃
Noise Less than 40dB
Annual Energy Production (@ 5 m/s wind speed ) about 1500 kWh

4. Maglev Vertical Axis Wind Turbine Main Features:

  • Magnetic levitation technology
  • Independent of the direction of the wind
  • Startup at low wind speed of 1m/s
  • Higher efficiency compared to traditional HAWT
  • Works even in turbulence
  • Visually pleasing appearance
  • Turbine construction is resistant to gale 60m/s (132MPH)
  • Robustness and adaptation to all possible environmental conditions thanks to material of aluminum alloy or stainless steel
  • Design life: at least 20 years
  • Noise: Tested by China National Machinery Quality Inspection Centre at 12m/s: <40db
