1J79 soft magnetic nickel-iron alloy permalloy
1J79 soft magnetic nickel-iron alloy permalloy
Specifications
Place of Origin :
Suzhou, China
Brand Name :
AIWEN
Certification :
SGS, BV, TUV
Model Number :
1J79
Technique :
Cold Rolled
Standard :
GB
Thickness :
0.1-6mm
Width :
5-500mm
Length :
In coil
Application :
Various
Product scope :
Wire, strip, bar, tube
MOQ :
100kg
Price :
Available per request
Packaging Details :
Carton, wooden box
Delivery Time :
30 days
Payment Terms :
T/T
Supply Ability :
10MT/month
Grade :
1J79
Description

1J79 Alloy 4 soft magnetic nickel-iron alloy permalloy

General Introduction

Permalloy is a nickel-iron magnetic alloy, with about 20% iron and 80% nickel content. it is notable for its very high magnetic permeability, which makes it useful as a magnetic core material in electrical and electronic equipment, and also in magnetic shielding to block magnetic fields. Commercial permalloy alloys typically have relative permeability of around 100,000, compared to several thousand for ordinary steel.

In addition to high permeability, its other magnetic properties are low coercivity, near zero magnetostriction, and significant anisotropic magnetoresistance. The low magnetostriction is critical for industrial applications, allowing it to be used in thin films where variable stresses would otherwise cause a ruinously large variation in magnetic properties. Permalloy's electrical resistivity can vary as much as 5% depending on the strength and the direction of an applied magnetic field. Permalloys typically have the face centered cubic crystal structure with a lattice constant of approximately 0.355 nm in the vicinity of a nickel concentration of 80%. A disadvantage of Permalloy is that it is not very ductile or workable, so applications requiring elaborate shapes, such as magnetic shields, are made of other high permeability alloys such as mu metal. Permalloy is used in transformer laminations and magnetic recording heads.

Typical applications of 1J79:

Transformers, current transformers, magnetic amplifiers, chokes core and magnetic shielding

Standard Composition of Permalloy 1J79

Grade

Composition (by weight)(%)

C

S

P

Mn

Si

Ni

M0

Cu

1J79

0.03

0.020

0.020

0.60~1.10

0.30~0.50

78.5~80.0

3.8~4.1

≤0.2

Average coefficient of linear expansion of 1J79

Grade

coefficient of linear expansion at temperature/(×10-6/K)

20~

100°C

20~

200°C

20~

300°C

20~

400°C

20~

500°C

20~

600°C

20~

700°C

20~

800°C

20~

900°C

lJ79

10.3~

lO-8

10.9~

11.2

11.4~

12.9

11.9~

12.5

12.3~

13.2

12.7~

13.4

13.1~

13.6

13.4~

13.6

13.2~

13.7

Mechanical property of 1J79

Grade

Electrical

resistivity/(μΩ·m)

Density/(g/cm3)

Curie point(°C)

Saturation magnetostriction coefficient

(× 10-2)

HBs

Tensile strength

MPa

Yield strength MPa

Elongation

(%)

Hard

Soft

Hard

Soft

Hard

Soft

Hard

Soft

1J79

O.55

8.6

450

2

210

120

1030

560

980

150

3

50

Prouct type

Wire, strip, bar...
