CNLINKO Waterproof IP68 USB 3.0 Connector Panel Mount Usb with Dust Cover for Cabinet Box
CNLINKO Waterproof IP68 USB 3.0 Connector Panel Mount Usb with Dust Cover for Cabinet Box
CNLINKO Waterproof IP68 USB 3.0 Connector Panel Mount Usb with Dust Cover for Cabinet Box
CNLINKO Waterproof IP68 USB 3.0 Connector Panel Mount Usb with Dust Cover for Cabinet Box
CNLINKO Waterproof IP68 USB 3.0 Connector Panel Mount Usb with Dust Cover for Cabinet Box
CNLINKO Waterproof IP68 USB 3.0 Connector Panel Mount Usb with Dust Cover for Cabinet Box
CNLINKO Waterproof IP68 USB 3.0 Connector Panel Mount Usb with Dust Cover for Cabinet Box
CNLINKO Waterproof IP68 USB 3.0 Connector Panel Mount Usb with Dust Cover for Cabinet Box
CNLINKO Waterproof IP68 USB 3.0 Connector Panel Mount Usb with Dust Cover for Cabinet Box
CNLINKO Waterproof IP68 USB 3.0 Connector Panel Mount Usb with Dust Cover for Cabinet Box
CNLINKO Waterproof IP68 USB 3.0 Connector Panel Mount Usb with Dust Cover for Cabinet Box
CNLINKO Waterproof IP68 USB 3.0 Connector Panel Mount Usb with Dust Cover for Cabinet Box
Specifications
Place of Origin :
Guangdong, China
Brand Name :
Cnlinko
Model Number :
DH-24-USB3.0-P01&DH-24-USB3.0-S01
Certification :
CE,ROHS,CCC,ISO9001
MOQ :
2
Price :
$12-13
Shape :
ROUND
IP level :
ip68
Type :
usb
Application :
Data
Gender :
male and female, Female +male
Protection level :
IP68
Pin :
9pin
Current rating(A) :
1.5A
Shell & Insulated Parts :
High Performance Engineer Plastic
Hardware Matel :
Zinc Alloy (pearl hard chromium)
Connecting mode :
plug/unplug
Withstand voltage :
500V
Description

CNLINKO Waterproof IP67 usb 3.0 connector panel mount usb with dust cap for cabinet box

Product Description

CNLINKO Waterproof IP68 USB 3.0 Connector Panel Mount Usb with Dust Cover for Cabinet BoxCNLINKO Waterproof IP68 USB 3.0 Connector Panel Mount Usb with Dust Cover for Cabinet BoxCNLINKO Waterproof IP68 USB 3.0 Connector Panel Mount Usb with Dust Cover for Cabinet BoxCNLINKO Waterproof IP68 USB 3.0 Connector Panel Mount Usb with Dust Cover for Cabinet BoxCNLINKO Waterproof IP68 USB 3.0 Connector Panel Mount Usb with Dust Cover for Cabinet BoxCNLINKO Waterproof IP68 USB 3.0 Connector Panel Mount Usb with Dust Cover for Cabinet BoxCNLINKO Waterproof IP68 USB 3.0 Connector Panel Mount Usb with Dust Cover for Cabinet BoxCNLINKO Waterproof IP68 USB 3.0 Connector Panel Mount Usb with Dust Cover for Cabinet BoxCNLINKO Waterproof IP68 USB 3.0 Connector Panel Mount Usb with Dust Cover for Cabinet Box

Specifications
Specifications
Connecting mode Latching Lock connect
Protection level IP65/IP67
Cable specification 26AWG-24AWG
Diameter range Φ5mm ~Φ6.5mm
Contact diameter×Qty 9PIN(3.0)&4PIN(2.0)
Current rating(A) 1.5A
Temperature rise

/
Operating voltage(AC.V.rms) /
Withstanding voltage(AC.V)1min 1000V
Contact resistance <30mΩ
Insulation resistance >500MΩ
Durability ≥500 mating&unmating cycles
Temperature rating -40°C~80°C
Method of connecting cable Soldering
Prevent the combustion level UL94-V0
Material
shell & Insulated parts High performance engineering plastics
Hardware metal Zinc alloy(pearl hard chromium)
Contact pin Copper alloy(gold-plated 4U)
Spring Stainless steel
Sealing Silica gel
Main characteristics
Sealed against dust and fluid (IP65/IP67)
Vibration resistance,impact resistance,stretching resistance
socket with cover
Application industries
Stage equipment - The smart grid
Medical equipment - Server
Solar energy equipment - Ship equipment
Electric power equipment - Vehicle equipment
Communications equipment - Heavy machinery
