Household DC Inverter Air to Water Heat Pump with Copeland Compressor, 380V/3N/50Hz Power, and -30°C to 40°C Operation
Household DC Inverter Air to Water Heat Pump with Copeland Compressor, 380V/3N/50Hz Power, and -30°C to 40°C Operation
Specifications
Brand Name :
Meidibao
Model Number :
M-D25ADH
Certification :
CE
Place of Origin :
China
MOQ :
6units
Price :
negotiate a price
Payment Terms :
T/T
Supply Ability :
20units a day
Delivery Time :
25-30 days
Packaging Details :
Factory standard
Fan Direction :
Side
Color :
Galvanized
Power :
380V/3N/50Hz
Operation Condition :
-30°C-40°C
Compressor :
Copeland
Description
Household DC Inverter Air to Water Source Heat Pump with EVI Technology

This DC Inverter Air to Water Source Heat Pump is an all-in-one, energy-saving system designed to meet the heating, cooling, and domestic hot water needs of residential homes. Utilizing advanced inverter technology, it adjusts output intelligently based on real-time demand—delivering maximum comfort with minimum energy consumption.

Key Features
  • DC Inverter Technology
  • All-Season Comfort
  • Air Source Heat Pump Water Heating
  • Hot Water Supply up to 60°C
  • Reliable Performance
Applications
  • Residential Heating: Warm up homes effectively without skyrocketing energy bills
  • Commercial Spaces: Ideal for offices, hotels, and retail stores requiring consistent, efficient heating
  • Industrial Use: Suited for large-scale heating needs in warehouses or factories
  • Swimming Pools: Maintain pool water at a comfortable temperature year-round
Why Choose Meidibao EVI Heat Pump?
  • Energy Saving
  • Multi-Functionality
  • Stable and Silent Operation
  • Environmentally Friendly
  • Smart Control Options
  • Wide Ambient Temperature Range
  • Durable and Low Maintenance
  • Easy Installation with Monoblock Design
Technical Specifications
Model M-D25ADH
Heating Capacity Range 10.8-36 kW (36849-122832 BTU/h)
Heating Power Input Range 2.5-9.5 kW
Cooling Capacity Range 6.5-21.6 kW (22178-73699 BTU/h)
Cooling Power Input Range 2.1-8.8 kW
Frequency 30-90 Hz
ErP Level (35℃) A++
ErP Level (55℃) A+
Power Supply 3N 380V 50HZ
Max Running Current 21.8 A
Refrigerant Type R410A
Refrigerant Quantity 3.3 kg
Compressor Brand Mitsubishi Electric
Water Pump Brand WiLo
Water Connection 1"
Water Flow 6.2 m³/h
Water Pressure Drop 10 kPa
Water Pump Head 11.8 m
Fan Motor Quantity 2
Motor Power Input (max) 136 W
Motor Power Input (min) 18 W
Fan Speed (max) 850 rpm
Fan Speed (min) 300 rpm
Pressure Sensor 1 0-20 Bar
Pressure Sensor 2 0-45 Bar
Noise 58 dB(A)
Net Weight 183 kg
Gross Weight 235 kg
Net Dimension (L/W/H) 1370×580×1525 mm
Shipping Dimension (L/W/H) 1480×690×1690 mm
Energy Efficiency Advantage

Under ideal weather conditions, heat pump water heaters produce three times the energy used to power the heat pump. In other words, heat pump water heaters use one-third of the electricity of conventional electric water heaters. CUB estimates that the average residential customer would save a lot of money per month using a MEIDIBAO heat pump water heater.
