Meidibao Heat Pump with Intelligent Control and Precise Regulation for High-Temperature Applications
Meidibao Heat Pump with Intelligent Control and Precise Regulation for High-Temperature Applications
Specifications
Brand Name :
Meidibao
Model Number :
MDB-10HG
Certification :
CE
Place of Origin :
China
MOQ :
3 Unit
Price :
negotiate a price
Payment Terms :
T/T
Supply Ability :
10 Unit/Units per Month
Delivery Time :
Specific to the order based on regular products 5 to 7 days. Custom made for 30 days
Packaging Details :
Factory standard packing
Name :
Meidibao Heat Pump
Type :
fixed
Origin :
Guangdong Province China
Working temp :
28-80℃
dimension :
1360*750*1360
weight :
208
Description
Intelligent Control and Precise Regulation of High-Temperature Heat Pumps
The Meidibao Air Source Heat Pump is an energy-efficient and high-performance solution for residential and commercial heating and hot water applications. Equipped with a Copeland Scroll Compressor and using R410A refrigerant, this unit ensures optimal energy efficiency, reliability, and eco-friendliness.
Key Features
  • Intelligent control system automatically adjusts operating parameters based on ambient temperature and load
  • Precise temperature and humidity control for unattended operation
  • Remote monitoring capability enhances management efficiency and equipment stability
Technical Specifications
Specification Unit Value
Model - KFXRSG-69II
Factory Model Number - MDB-20HG
Applicable Ambient Temperature °C 0-43
Power Supply Specification - 380V3N-50HZ
Rated Heating Capacity kw 70
Nominal Input Power kw 19.2
Maximum Operating Current A 46
Hot Water Output L/H 760
Refrigerant - High-temperature dedicated type
Air Outlet Mode - Push out the wind
Protection Class - IPX4
Outlet Water Temperature - 28-60℃
Inlet and Outlet Port Type MM DN32
Noise DB(A) ≤55
Dimensions MM 1600×1100×1800
Weight KG 633
Key Advantages
  • Water and electricity separation design eliminates electric leakage risk
  • Uses low-GWP value environmentally friendly refrigerants
  • No combustion process - emits no waste gas or residue
  • Meets green production standards
  • Wide range of applications: industrial drying, commercial heating, agricultural breeding
  • Waste heat recovery function can replace traditional steam boilers
  • Solves heat waste problems effectively
Product Images
Meidibao Heat Pump with Intelligent Control and Precise Regulation for High-Temperature Applications Meidibao Heat Pump with Intelligent Control and Precise Regulation for High-Temperature Applications Meidibao Heat Pump with Intelligent Control and Precise Regulation for High-Temperature Applications
