37KW Belt driven air-cooling oil inject screw compressor
37KW Belt driven air-cooling oil inject screw compressor
37KW Belt driven air-cooling oil inject screw compressor
37KW Belt driven air-cooling oil inject screw compressor
37KW Belt driven air-cooling oil inject screw compressor
37KW Belt driven air-cooling oil inject screw compressor
37KW Belt driven air-cooling oil inject screw compressor
37KW Belt driven air-cooling oil inject screw compressor
Specifications
Brand Name :
AIRERA
Model Number :
AGFD-37B D
Certification :
ISO、CE、TUV
Place of Origin :
made in China
MOQ :
1 unit
Price :
Negotiable
Payment Terms :
TT/LC,Western Union,D/P,D/A
Supply Ability :
2,000-3,000 per month
Delivery Time :
5-15 days
Packaging Details :
wooden case
Cooling air flow（m3/hr） :
9200
Application :
Medical, Pharmaceutical, Food Processing
Oil Content :
Oil inject
Working Pressure :
0.8-1.5Bar
Cooling type :
Air cooling
Driven type :
Belt driven
Description
AIRERA 37kW Belt-Driven Screw Compressor: High-Output Efficiency with Streamlined Maintenance

As a cornerstone of the AIRERA lineup, this 37kW (50HP) belt-driven oil-injected screw compressor is engineered to provide a rock-solid air supply for demanding production lines. We’ve optimized the high-precision transmission system to strike the perfect balance between power transfer and cost-effective maintenance, ensuring peak performance across the 0.8–1.3MPa pressure range. Built for heavy-duty cycles, the reinforced air-cooling design effectively manages thermal loads, preserving oil integrity and extending bearing life even in harsh environments. With an integrated smart control system monitoring every critical parameter, this unit eliminates operational guesswork and embodies the "reliability-first" engineering that defines the AIRERA brand—making it the definitive choice for enterprises prioritizing low downtime and high ROI.

Advantages of AGFD Oil-Inject Air Screw Compressor:

  • Pick-up French Schneider white-color high-end contractor to keep more durable in extreme environment

37KW Belt driven air-cooling oil inject screw compressor

  • Advanced Intelligent colorful touchable control system for simple& easy operation

    37KW Belt driven air-cooling oil inject screw compressor


  • The patented OPTI belt transmission, this unique design to ensure the belt tensioning force by the weight of the motor and start Torque, the design service life is up to 25,000 hours, transmission efficiency can be as high as above 98%.

37KW Belt driven air-cooling oil inject screw compressor


Technical Specifications - 37KW Air Cooling Compressor
37KW Air Cooling Compressor Parameters
ITEM UNIT MODEL AGFD-37
Free air delivery m³/min 6.6-4.3
Max. working pressure MPa 0.8-1.5
Compressor type
Oil inject screw compressor
Cooling type
Air cooling
Driven type
Belt driven
Inlet status - Temperature ℃ ≤55
Inlet status - Pressure MPa Atmospheric pressure
Inlet status - Relative humidity
≤90%
Noise Level dB(A) ≤72
Residual oil content ppm ≤1
Drive rotor speed rpm 4550~3250
Compressed air outlet temperature ℃ Ambient temperature＋10
Cooling air flow m³/hr 9200
Control mode
Intelligent controller
Safety valve set pressure MPa 0.88 ~ 1.6
Lubricating water volume L 30
Compressed air outlet connection
G1-1/4
Dimension - L mm 1380
Dimension - W mm 1000
Dimension - H mm 1300
Net Weight kg 830
Motor - Model
Y2180L2-2
Motor - Speed rpm 2950
Motor - Rated Power KW 37
Motor - Service factor
1.2
Motor - Protection type
IP55
Motor - Efficiency
IE3
Motor - Startup mode
ʏ-Δ starting
Motor - Voltage V 380(Special on request)
Motor - Frequency Hz 50(Special on request)
Motor - Rated current A 69.8
Motor - Weight of motor kg 250
37KW Belt driven air-cooling oil inject screw compressor
AIRERA 37kW Screw Air Compressor: Frequently Asked Questions (FAQ)
How does the cooling system perform under heavy industrial loads?
We have overhauled the thermal architecture to create an exceptional air-cooling system. Compared to previous generations, the heat dissipation efficiency has been boosted by 20-30%. This ensures the compressor maintains an optimal $T_{operating}$ even in harsh environments, significantly extending the life of the lubricating oil and internal components.
What are the energy-saving benefits of the motor used in this compressor?
The machine is equipped with a high-efficiency IE3 (IP55) motor that meets CE and MEPS standards. With a Service Factor of 1.2, this motor improves overall energy efficiency by 15% compared to standard motors, directly reducing your factory's electricity overhead.
How does the "Driving Protection System" benefit long-term maintenance?

The unique integrated protection system is designed to shield the drive assembly from premature wear. By stabilizing the transmission and reducing vibration, it significantly extends the service life of the driving components, leading to lower total cost of ownership.
