AIRERA AGSD-15 15kW Screw Air Compressor with Tank Mounted
AIRERA AGSD-15 15kW Screw Air Compressor with Tank Mounted
AIRERA AGSD-15 15kW Screw Air Compressor with Tank Mounted
AIRERA AGSD-15 15kW Screw Air Compressor with Tank Mounted
AIRERA AGSD-15 15kW Screw Air Compressor with Tank Mounted
AIRERA AGSD-15 15kW Screw Air Compressor with Tank Mounted
AIRERA AGSD-15 15kW Screw Air Compressor with Tank Mounted
AIRERA AGSD-15 15kW Screw Air Compressor with Tank Mounted
AIRERA AGSD-15 15kW Screw Air Compressor with Tank Mounted
AIRERA AGSD-15 15kW Screw Air Compressor with Tank Mounted
AIRERA AGSD-15 15kW Screw Air Compressor with Tank Mounted
AIRERA AGSD-15 15kW Screw Air Compressor with Tank Mounted
Specifications
Brand Name :
AIRERA
Model Number :
AGSD-15
Certification :
ISO、CE、TUV
Place of Origin :
made in China
MOQ :
1 unit
Price :
520-30,000 USD
Payment Terms :
L/C,T/T
Supply Ability :
2,000-3,000 per month
Description

Product Overview

The AIRERA AGSD-15 is a 15kW tank mounted rotary screw air compressor designed for workshops and light industrial facilities that require a complete, space-saving compressed air solution.

Featuring an integrated receiver tank and direct drive system, this all-in-one unit delivers stable compressed air with minimal installation requirements. Simply connect power and start operating – no complex piping or separate tank installation needed.

Perfect for automotive repair shops, small to medium manufacturing facilities, and maintenance workshops, the AGSD-15 combines reliable performance with compact footprint and easy installation.

AIRERA AGSD-15 15kW Screw Air Compressor with Tank Mounted

Key Features

Integrated Tank Mounted Design
Complete solution with compressor and receiver tank in one unit, saving floor space and eliminating separate tank installation.

Direct Drive System
Eliminates belts and pulleys for higher transmission efficiency and reduced maintenance requirements.

High Efficiency Screw Airend
Precision engineered rotors provide continuous compressed air with low pulsation and high reliability.

Low Noise Operation
Advanced soundproofing keeps noise levels low for comfortable workshop installation.

Plug and Play Installation
Pre-wired and pre-tested, ready for immediate operation after power connection.

Intelligent Controller
Digital display allows real time monitoring of pressure, temperature and maintenance alerts.

AIRERA AGSD-15 15kW Screw Air Compressor with Tank Mounted

Technical Parameters

Technical Data of Rotorcomp AGSD(C) series Screw Air Compressor
ITEM UNIT MODEL


AGSD-15
Compressor
¹ Capacity (f.a.d.) at gauged pressure m3/min 2.35 2.3 2.05
Max. working pressure MPa 0.7 0.8 1
Compressor type
Oil inject screw compressor
Cooling type
Air cooling
Driven type
Direct driven
Inlet status Temperature ℃ ≤45

Pressure MPa Atmospheric pressure

Relative humidity
≤90%
Cooling air flow m3/hr 5300
Control mode
Intelligent controller
Safety valve set pressure MPa 0.77 0.88 1.1
Lubricating oil volume L 10
Lubricating oil brand
ROTORCOMP
Drive rotor speed rpm 2930
Main Motor Rated Power KW 15

Type
Fix speed

Speed rpm 2930

Service factor
1.2

Protection type
IP55

Insulation class ISO F

Efficiency
IE3

Startup mode
ʏ-Δ starting

Voltage(Special on request) V 380

Frequency(Special on request) Hz 50

Rated current A 27.86
Fan Motor Rated Power KW 0.37

Type
Fix speed

Speed rpm 1470

Protection type
IP55

Insulation class ISO F

Startup mode
Direct starting

Voltage(Special on request) V 380

Frequency(Special on request) Hz 50

AIRERA AGSD-15 15kW Screw Air Compressor with Tank Mounted

FAQ

Q1: What are the advantages of a tank mounted compressor?
Tank mounted compressors save floor space, reduce installation time and cost, and provide a complete ready-to-use solution without requiring separate tank purchase and piping.

Q2: Is a 15kW compressor suitable for continuous operation?
Yes. The AGSD-15 is designed for reliable performance in workshop and light industrial environments with typical duty cycles.

Q3: What pressure options are available?
This model can be configured for 8 bar, 10 bar, or 13 bar working pressure based on your application requirements.

Q4: How much maintenance does it require?
Routine maintenance includes regular air filter and oil filter changes. The direct drive design eliminates belt replacements.

Q5: Can voltage be customized for different countries?
Yes. Voltage and frequency can be customized according to destination country requirements.
