Endress+Hauser PMP51-30PN90 | Cerabar S Pressure Transmitter 4-20mA HART
Endress+Hauser PMP51-30PN90 | Cerabar S Pressure Transmitter 4-20mA HART
Endress+Hauser PMP51-30PN90 | Cerabar S Pressure Transmitter 4-20mA HART
Endress+Hauser PMP51-30PN90 | Cerabar S Pressure Transmitter 4-20mA HART
Specifications
Delivery Time :
Negotiable
Place of Origin :
DE
Supply Ability :
100pcs per month
Packaging Details :
carton
Electrical Rating :
G
Certifications :
S
Ambient Temperature :
-
Brand Name :
Endress+Hauser
Payment Terms :
T/T,XT,ALIPAY
Model Number :
PMP51-30PN90
Price :
Negotiable
Certification :
ATEX
MOQ :
1
Power Supply :
1
Description

Endress+Hauser PMP51-30PN90 | Cerabar S Pressure Transmitter 4-20mA HART

Endress+Hauser PMP51-30PN90 digital pressure transmitter. Cerabar S PMP51 series, 4-20mA HART, 0.1% accuracy, metal sensor, 316L wetted parts, -40 to 85°C.

Product Overview

The Endress+Hauser PMP51-30PN90​ is a digital gauge pressure transmitter​ from the Cerabar S PMP51 series. It features a piezoresistive silicon sensor with welded metal diaphragm​ for high-pressure measurement of liquids and gases. This specific model (30PN90) is configured with a 4-20mA HART output, aluminum housing, and is designed for demanding process applications in chemical, oil & gas, and industrial environments requiring high accuracy and robustness.

Technical Specifications (Measurement & Electrical)

Parameter

Specification

Model / Order Code​

PMP51-30PN90​

Product Series​

Cerabar S PMP51

Measurement Type​

Gauge Pressure​

Output Signal​

4...20 mA HART​ (2-wire)

Reference Accuracy​

≤ 0.1 %​ (of span)

Long-Term Stability​

≤ 0.1 % URL / year

Supply Voltage​

11.5 ... 45 V DC​

Turn Down Ratio​

20:1​

Sensor Technology​

Piezoresistive Silicon (Metal Isolating Diaphragm)

Technical Specifications (Mechanical & Process)

Parameter

Specification

Housing Material​

Die-Cast Aluminum​ (Single Chamber)

Wetted Parts Material​

316L Stainless Steel​

Pressure Range (URL)​

0 ... 400 bar​ (Adjustable)

Max. Overpressure Limit​

600 bar​

Process Temperature​

-40 ... +130 °C

Ambient Temperature​

-40 ... +85 °C

Protection Rating​

IP66 / IP67 (NEMA 4X)

Process Connection​

Thread / Flange (Configurable)

Key Features

  • Metal Sensor Durability:​ The welded metal (316L) isolating diaphragm​ provides high resistance to overpressure, corrosion, and aggressive media, ensuring long-term stability.

  • High Turndown & Flexibility:​ 20:1 turndown ratio​ allows for significant adjustment of the measuring range in the field without sacrificing the high 0.1% accuracy.

  • Integrated Diagnostics:​ Features comprehensive self-monitoring and HistoROM​ data storage for simplified maintenance and commissioning traceability.

  • SIL Compliance:​ Designed to meet IEC 61508​ standards for SIL 2​ applications, making it suitable for safety instrumented systems.

Applications

  • Process Pressure Monitoring:​ Continuous pressure measurement in pipelines, vessels, and reactors in chemical and petrochemical plants.

  • Hydrostatic Level Measurement:​ Level calculation in open or closed tanks using the hydrostatic pressure method.

  • High-Pressure Applications:​ Suitable for hydraulic systems, compressor discharge, and pump monitoring up to 400 bar.

Endress+Hauser PMP51-30PN90 | Cerabar S Pressure Transmitter 4-20mA HART

More Products

Pepperl Fuchs Safety Barrier

Allen Bradley PLC Controllers

SICK Instruments

Festo Cylinder

IFM Sensors

About ACH

Founded in 2012, ACH is a top-tier distributor of industrial automation products, supplying genuine devices from leading brands like ABB, P+F, E&H, AB, MTL to emerging markets worldwide. Our mission is to provide 100% Genuine products at the most competitive prices, helping customers reduce costs and strengthen their market position.

Endress+Hauser PMP51-30PN90 | Cerabar S Pressure Transmitter 4-20mA HART
Frequently Ask & Questions
Are preferential prices available?

Long-term brand partners can get competitive product prices. At the same time, ACH controls the profit per order to 5%, providing the most competitive prices.

Are the Products Genuine OEM Units?

Yes, all products from ACH are certified genuine OEM units. We acquire our inventory through official OEM channels and trusted third-party suppliers, ensuring every item is authentic and reliable.

How will you arrange shipment?

We'll handle the shipping for you. Through our partnerships, we can secure competitive rates with major carriers like FedEx, DHL, TNT, and UPS, ensuring a smooth and cost-effective delivery.

What is the warranty of goods?

One-year Warranty.

How long is the logistics cycle of the product?

Products are divided into spot and futures, and the delivery period of different brands of products is also different. For details, please contact the ACH business manager.
