Endress+Hauser PTP33B-9UL90 | Hygienic Pressure Switch with IO-Link
Endress+Hauser PTP33B-9UL90 | Hygienic Pressure Switch with IO-Link
Endress+Hauser PTP33B-9UL90 | Hygienic Pressure Switch with IO-Link
Endress+Hauser PTP33B-9UL90 | Hygienic Pressure Switch with IO-Link
Endress+Hauser PTP33B-9UL90 | Hygienic Pressure Switch with IO-Link
Endress+Hauser PTP33B-9UL90 | Hygienic Pressure Switch with IO-Link
Specifications
Certifications :
S
Place of Origin :
DE
Electrical Rating :
G
Power Supply :
1
Packaging Details :
carton
Certification :
ATEX
MOQ :
1
Brand Name :
Endress+Hauser
Payment Terms :
T/T,XT,ALIPAY
Model Number :
PTP33B-9UL90
Price :
Negotiable
Supply Ability :
100pcs per month
Ambient Temperature :
-
Delivery Time :
Negotiable
Description

Endress+Hauser PTP33B-9UL90 | Hygienic Pressure Switch with IO-Link

Endress+Hauser PTP33B-9UL90 hygienic pressure switch. 4-40 bar range, 316L stainless steel, IO-Link & dual PNP outputs, 3-A & EHEDG certified for food/pharma.

Product Overview

The Endress+Hauser PTP33B-9UL90​ is a hygienic pressure switch/transmitter​ from the Ceraphant PTP33B​ series. It features a metal diaphragm sensor​ (316L stainless steel) designed for absolute and gauge pressure​ monitoring in sanitary applications. This specific variant (-9UL90) is configured with dual PNP switching outputs​ and IO-Link communication​ for easy integration into automated process control systems in the food, beverage, and pharmaceutical industries.

Technical Specifications (Performance & Electrical)

Parameter

Specification

Model​

PTP33B-9UL90​

Function​

Pressure Switch / Compact Transmitter

Measuring Range​

+400 mbar ... +40 bar​ (6 ... 600 psi)

Reference Accuracy​

≤ ±0.3 %​ (Platinum version)

Outputs​

2x PNP Switching Outputs​ + IO-Link SIO​

Supply Voltage​

10 ... 30 V DC​

Long-term Stability​

≤ ±0.2 % of URL / year

Technical Specifications (Mechanical & Process)

Parameter

Specification

Process Connection​

Hygienic Connection​ (e.g., Tri-Clamp, DIN 11851)

Wetted Parts​

Stainless Steel 1.4435 / 316L​

Process Temperature​

-10 ... +100 °C​ (+14 ... +212 °F)

Ambient Temperature​

-20 ... +70 °C (-4 ... +158 °F)

Max. Overpressure​

160 bar​ (2320 psi)

Certifications​

3-A, EHEDG, CIP/SIP capable

Key Features

  • Hygienic Design:​ Flush-mounted diaphragm and 316L construction meet 3-A and EHEDG standards, ensuring compliance with strict food and pharmaceutical cleaning protocols (CIP/SIP).

  • IO-Link Smart Sensor:​ Enables remote parameter setting, device diagnostics, and digital process value readback via the IO-Link interface, reducing commissioning time.

  • Dual Switching Logic:​ Two independent PNP transistor outputs can be configured for window functions, alarm thresholds, or pump control directly from the device.

  • High Overpressure Resistance:​ Withstands up to 160 bar, providing a high safety margin against pressure spikes in utility and process lines.

Applications

  • Food & Beverage Processing:​ Pressure monitoring in pasteurizers, tanks, and filling machines requiring hygienic design.

  • Pharmaceutical Bioreactors:​ Level and pressure control in vessels with strict clean-in-place (CIP) requirements.

  • Utility Monitoring:​ Compressed air and gas pressure supervision in packaging and automation machinery.

Endress+Hauser PTP33B-9UL90 | Hygienic Pressure Switch with IO-Link
