Description
Endress+Hauser CUS52D-AA1AA3 | Memosens Turbidity/Nephelometric Sensor, 0-4000 NTU
Endress+Hauser CUS52D-AA1AA3 digital nephelometric turbidity sensor. Memosens 2.0, 0-4000 NTU range, 90° scattered light ISO 7027, IP68, for wastewater & drinking water.

Product Overview

The Endress+Hauser CUS52D-AA1AA3​ is a digital nephelometric turbidity sensor​ from the ViSolid CUS52D series, compliant with ISO 7027 (90° scattered light method). It measures suspended solids and turbidity in water and wastewater with a range of 0–4000 NTU (FNU). Featuring Memosens 2.0 digital technology, it offers contactless signal transmission, lab calibration capability, and integrated sensor diagnostics. The sensor is rated IP68​ for continuous submersion and is suitable for both drinking water monitoring and demanding wastewater applications.

Technical Specifications (Measurement & Electrical)

Parameter
Specification
Model / Order Code​
CUS52D-AA1AA3​
Measuring Principle​
Nephelometric (90° Scattered Light)​ per ISO 7027
Measured Variable​
Turbidity (NTU / FNU / mg/L TSS*)
Measuring Range​
0.001 … 4000 NTU (FNU)​
Resolution​
0.001 NTU (< 9.99 NTU), 0.01 NTU (10–99.9 NTU), 0.1 NTU (> 100 NTU)
Technology​
Memosens 2.0​ (Digital, Inductive)
Integrated Sensor​
Pt1000​ (Temperature Compensation)
Connection​
Memosens Inductive Plug (C8Y)

Technical Specifications (Mechanical & Process)

Parameter
Specification
Sensor Body Material​
POM / Stainless Steel 316L​ (depending on variant)
Process Connection​
G1" / NPT 1"​ (Male Thread — check order code detail)
Immersion Length​
~200 mm (typical with protection guard)
Process Temperature​
0 … +50 °C​ (non-freezing)
Process Pressure​
≤ 10 bar​
Protection Rating​
IP68​ (Submersible)
Wiper / Cleaning​
Not included (CUS51D has wiper; CUS52D is simpler version)
*TSS correlation requires site-specific calibration.

Key Features

  • ISO 7027 Compliance:​ Uses 90° scattered light​ for accurate low-range turbidity measurement per international drinking water standards.
  • Memosens 2.0 Digital:​ Inductive coupling prevents corrosion and stores calibration data, sensor ID, and diagnostics in the sensor head — enables lab pre-calibration and plug-and-play replacement.
  • Wide Dynamic Range:​ From 0.001 NTU​ (drinking water clarity) up to 4000 NTU​ (raw wastewater), covering the full treatment train in a single device.
  • Robust Submersible Design:​ IP68-rated​ housing allows continuous immersion in open channels, tanks, or flow cells without additional enclosures.

Applications

  • Drinking Water Treatment:​ Final water clarity monitoring post-filtration and post-disinfection.
  • Wastewater Treatment:​ Raw influent turbidity, clarifier effluent, and final effluent compliance monitoring.
  • Industrial Process Water:​ Turbidity monitoring in cooling towers, RO pre-treatment, and rinse water loops.
  • Surface Water Monitoring:​ Environmental monitoring of rivers and lakes for sediment load assessment.
