Description

Endress+Hauser CPF81E-AA5LAD1 | Digital pH Electrode, 0-14 pH, NPT 3/4"

Endress+Hauser CPF81E-AA5LAD1 digital pH sensor. Memosens 2.0 technology, 0-14 pH range, NTC 30k, PTFE diaphragm, IP68, for harsh water & wastewater.

Product Overview

The Endress+Hauser CPF81E-AA5LAD1​ is a digital pH glass electrode​ from the Memosens CPF81E series. It features Memosens 2.0 digital technology​ for contactless signal transmission and lab calibration. Designed for harsh environments, it offers a 0–14 pH measuring range, integrated NTC 30k temperature sensor, and a PTFE ring diaphragm​ for resistance to fouling and poisoning ions.

Technical Specifications (Measurement & Electrical)

Parameter

Specification

Model / Order Code​

CPF81E-AA5LAD1​

Measuring Principle​

Potentiometric (pH Glass Electrode)

Measuring Range​

0 ... 14 pH​

Technology​

Memosens 2.0​ (Digital, Inductive)

Reference System​

Ag/AgCl, Gel, Double Chamber (KNO₃ bridge)

Junction / Diaphragm​

PTFE Ring Diaphragm​

Temperature Sensor​

NTC 30 kΩ​ (Integrated)

Connection​

Memosens Inductive Plug (C8Y)

Technical Specifications (Mechanical & Process)

Parameter

Specification

Housing Material​

PPS Plastic​

Process Connection​

NPT ¾"​ (Male Thread)

Immersion Length​

~150 mm (with Protection Guard)

Process Temperature​

0 ... 110 °C​ (L Version)

Process Pressure​

0.8 ... 11 bar (abs)​

Protection Rating​

IP68​ (Submersible)

Application Class​

Standard / Non-Hazardous Area (AA)

Key Features

  • Memosens 2.0 Digital:​ Inductive coupling eliminates moisture issues and stores calibration data in the sensor head for predictive maintenance.

  • Anti-Poisoning Design:​ Double-chamber reference​ with KNO₃ electrolyte​ provides high resistance to sulfide (S²⁻) and cyanide (CN⁻) poisoning.

  • Robust Construction:​ PPS housing​ and PTFE diaphragm​ ensure long-term stability in abrasive and chemically aggressive media.

  • Plug & Play:​ Pre-calibration capability allows lab calibration and quick sensor replacement without on-site recalibration.

Applications

  • Wastewater Treatment:​ pH monitoring in inlet, neutralization, and outlet stages.

  • Industrial Water:​ Cooling water, boiler feedwater, and chemical process control.

  • Mining & Minerals:​ Flotation processes and leaching applications with abrasive slurries.
