Endress+Hauser FTM50-AGG2A4A32AA | Liquiphant M Level Switch, 4-20mA HART, 316L, G1½"
Endress+Hauser FTM50-AGG2A4A32AA Liquiphant M vibrating fork level switch. 4-20mA HART, G1½" PN40, 316L wetted parts, -40 to 150°C, SIL 2/3, for liquid point level.

Product Overview

The Endress+Hauser FTM50-AGG2A4A32AA​ is a vibrating fork (tuning fork) level switch​ from the Liquiphant M FTM50 series, designed for point level detection of liquids​ (presence/absence) in tanks, pipes, and sumps. It features a G1½" PN40 process connection, 316L stainless steel wetted parts, and a 4-20mA HART output with integrated diagnostics. The fork frequency shifts when covered by liquid, triggering a solid-state relay and analog signal — unaffected by turbulence, foam, bubbles, or dielectric changes down to εᵣ > 1.5. This variant is SIL 2/3 certified​ and suitable for safety-relevant alarm/shutdown loops.

Technical Specifications (Electrical & Functional)

Parameter
Specification
Model / Order Code​
FTM50-AGG2A4A32AA​
Product Family​
Liquiphant M FTM50 (Vibrating Fork for Liquids)
Function​
Point Level Switch (High / Low Alarm)
Measured Variable​
Liquid Coverage of Fork (Covered / Uncovered)
Switching Output​
1 x SPDT Relay​ (Dry Contact — typically 8A @ 250V AC) + 4-20mA HART​ (Status/Diagnostics)
Supply Voltage​
18.5 … 53 V DC​ or 20 … 253 V AC​ (50/60 Hz) — depends on electronics version; HART version typically 24V DC loop
Switch Delay​
< 1 s (Cover / Uncover)
SIL Rating​
SIL 2 (SIL 3 by Architectural Constraint)​ per IEC 61508
Self-Monitoring​
Continuous — detects fork damage, electronics fault, coating buildup

Technical Specifications (Mechanical & Process)

Parameter
Specification
Process Connection​
G 1½" (BSP Parallel) Female Thread, PN 40​ (ISO 228-1)
Fork Length (Immersion)​
~67 mm (standard FTM50 short fork — verify from full code)
Wetted Parts Material​
316L (1.4404) Stainless Steel​
Housing Material​
Aluminum (Painted) or Stainless Steel (optional)
Process Temperature Range​
-40 … +150 °C​
Process Pressure Range​
-1 … +64 bar (PN 40 @ 20°C, derated with T)​
Medium Density (Min.)​
≥ 0.5 g/cm³ (typical for fork — consult datasheet for viscous media)
Protection Rating​
IP66 / IP67, NEMA 4X (with proper cable gland)
Approvals / Area​
ATEX, IECEx (Ex d / Ex e versions available), FM, CSA, WHG (overfill prevention)

Key Features

  • Fork Physics — Immune to Process Noise:​ Vibration damping only occurs when both tines are covered by liquid — ignores foam, bubbles, turbulence, and dielectric changes (εᵣ > 1.5).
  • No Calibration Required:​ Factory-tuned — install and wire; no sensitivity adjustment or teach-in needed.
  • SIL 2/3 Capable:​ Suitable for Safety Instrumented Functions (SIF) in overfill or dry-run protection loops.
  • HART Diagnostic Feedback:​ 4-20mA HART signal reports switch state, fork frequency, and device health to DCS/AMS for predictive maintenance.

Applications

  • Overfill / Low-Level Alarms:​ High-level alarm in storage tanks, day tanks, and IBCs.
  • Pump Protection:​ Dry-run detection in suction lines and pump sumps (low-level cut-out).
  • Interface / Emulsion Detection:​ Where media density difference is sufficient (liquid vs. gas or light/heavy liquid interface — limited application).
  • Hazardous Area Service:​ With appropriate Ex certification — suitable for chemical, petrochemical, and pharmaceutical tank farms.
Note: For smaller process connections (G¾", G1", flange)​ or high-temperature/high-pressure versions, see other FTM50 variants. For bulk solid (powder/granule) vibrating forks, use the Soliphant FTM20/21 series. The exact fork length, housing type (Al vs. SS), and Ex approval are defined by the full 10-character suffix — the model shown represents a typical G1½" PN40, 316L, HART-output Liquiphant M.
