High Efficiency NEMA 145TC 1.5 HP 90 Volt Industrial PMDC Motor
High Efficiency NEMA 145TC 1.5 HP 90 Volt Industrial PMDC Motor
High Efficiency NEMA 145TC 1.5 HP 90 Volt Industrial PMDC Motor
High Efficiency NEMA 145TC 1.5 HP 90 Volt Industrial PMDC Motor
Specifications
Model Number :
PMDC
Price :
Negotiation
Protection :
IP54
Supply Ability :
10000pcs per month
Name :
1.5HP PMDC Motor
Certification :
UL
Payment Terms :
T/T
Speed(RPM) :
1750rpm
Voltage :
90V
MOQ :
10 pcs
Delivery Time :
25 days
Frame :
145TC
Efficiency :
IEC
Packaging Details :
Cartons/pallet
Brand Name :
BM
Place of Origin :
China
Description

High Efficiency NEMA 145TC 1.5 HP 90 Volt Industrial PMDC Motor

1, High efficiency IP54 waterproof 1.5HP 90V permanent magnet DC motor with NEMA 145TC frame, 1750RPM constant torque brushed PMDC motor for conveyor, packaging machine, printing equipment, SCR/PWM speed control, Class F insulation, continuous S1 duty, CE certified.

2, 1.5HP 90V permanent magnet DC motor adopts NEMA standard 145TC frame with IP54 dust & splash-proof enclosure, specially designed for industrial variable speed DC drive systems with SCR and PWM controllers.

3, Equipped with Class F insulation, double shielded sealed ball bearings and rolled steel heavy-duty housing, the 145TC 90V 1.5HP DC motor supports continuous S1 duty cycle under 40℃ ambient temperature

Power
(HP)		 Speed
(RPM)		 Arm Volt NEMA Frame ENCL. Current
(Amp.)		 Torque
(In.Ibs)
1.5 1750 90 143/145 TEFC 16.0 54
1.5 1750 180 143/145 TEFC 8.0 54
1.5 2500 180 143/145 TEFC 8.0 38
1.5 3600 180 143/145 TEFC 8.0 26
2 1750 90 143/145 TEFC 19.0 72
2 1750 180 143/145 TEFC 9.5 72
2 2500 180 143/145 TEFC 9.5 50
3 1750 90 143/145 TEFC 28.0 108
3 1750 180 143/145 TEFC 14.0 108
3 2500 180 143/145 TEFC 14.0 76

High Efficiency NEMA 145TC 1.5 HP 90 Volt Industrial PMDC MotorHigh Efficiency NEMA 145TC 1.5 HP 90 Volt Industrial PMDC MotorHigh Efficiency NEMA 145TC 1.5 HP 90 Volt Industrial PMDC Motor

High Efficiency NEMA 145TC 1.5 HP 90 Volt Industrial PMDC Motor

High Efficiency NEMA 145TC 1.5 HP 90 Volt Industrial PMDC Motor

FAQ
Q: Are you Factory or Trading Company?
A: We are Factory. That has been focusing on motors and accessories for more than 20 years.

Q: What is your warranty?
A: Our warranty is One Year. Any parts damaged within warranty. We will provide new one for free and supply the solution.

Q: What kind of motor can you supply?
A: Single Phase Motor, Three Phase Motor, NEMA standard motor, Explosion Proof Motor etc.

Q: Do you offer OEM Service?
A: Yes. We offer OEM/ODM service.

Q: What is your lead Time?
A: Usually 10 days. Precise Time depend on Qty.
