90V 1HP 24V NEMA 56C Electric PMDC DC Motor Brushed Motor Gear Motor
90V 1HP 24V NEMA 56C Electric PMDC DC Motor Brushed Motor Gear Motor
90V 1HP 24V NEMA 56C Electric PMDC DC Motor Brushed Motor Gear Motor
90V 1HP 24V NEMA 56C Electric PMDC DC Motor Brushed Motor Gear Motor
90V 1HP 24V NEMA 56C Electric PMDC DC Motor Brushed Motor Gear Motor
90V 1HP 24V NEMA 56C Electric PMDC DC Motor Brushed Motor Gear Motor
90V 1HP 24V NEMA 56C Electric PMDC DC Motor Brushed Motor Gear Motor
90V 1HP 24V NEMA 56C Electric PMDC DC Motor Brushed Motor Gear Motor
Specifications
Brand Name :
BM
Model Number :
PMDC 1hp
Certification :
UL
Place of Origin :
China
MOQ :
10 pcs
Price :
Negotiation
Payment Terms :
T/T
Supply Ability :
10000pcs per month
Delivery Time :
25 days
Packaging Details :
Cartons/pallet
Name :
1HP Brushed motor
Speed(RPM) :
1750rpm
Power :
1hp
Efficiency :
IEC
Voltage :
90v
Frame :
56C
Description

90V 1HP 24V NEMA 56C Electric PMDC DC Motor Brushed Motor Gear Motor

1. Now we can manufacture motors with voltage from 12v to 300v ,power from 40w to 3000w,speed from 500 to 6000rpm.

2. Flange:NEMA 56C ,NEMA 48C ,IEC and so on

3. Class F ,IP54

4. Appreciations:widely used in printing and packing machines,working line,machine tools,gym equipments,fans,various mechanical and automatic control systems.

Power(HP) Speed(RPM) Arm Volt NEMA FRAME ENCL. Curret(Amp.) Torque(In.Ibs) App.Weights(Ibs)
1/4 1750 12 56C TEFC 21.0 9 21
1/4 1750 24 56C TEFC 10.5 9 21
1/3 1750 12 56C TEFC 27.0 12 23
1/3 1750 24 56C TEFC 13.5 12 23
1/2 1750 12 56C TEFC 39.0 18 25
1/2 1750 24 56C TEFC 20.0 18 25
3/4 1750 12 56C TEFC 63.6 27 30
3/4 1750 24 56C TEFC 31.8 27 30
3/4 3600 12 56C TEFC 63.6 13 23
3/4 3600 24 56C TEFC 31.8 13 23
1 1750 12 56C TEFC 80.0 36 32
1 1750 24 56C TEFC 40.0 36 32
1 3600 12 56C TEFC 80.0 17.6 25
1 3600 24 56C TEFC 40.0 17.6 25
1.5 1750 24 56C TEFC 60.0 54.3 43
1.5 3600 24 56C TEFC 60.0 26.4 30

90V 1HP 24V NEMA 56C Electric PMDC DC Motor Brushed Motor Gear Motor90V 1HP 24V NEMA 56C Electric PMDC DC Motor Brushed Motor Gear Motor90V 1HP 24V NEMA 56C Electric PMDC DC Motor Brushed Motor Gear Motor

90V 1HP 24V NEMA 56C Electric PMDC DC Motor Brushed Motor Gear Motor

90V 1HP 24V NEMA 56C Electric PMDC DC Motor Brushed Motor Gear Motor

90V 1HP 24V NEMA 56C Electric PMDC DC Motor Brushed Motor Gear Motor

FAQ
Q: Are you Factory or Trading Company?
A: We are Factory. That has been focusing on motors and accessories for more than 20 years.

Q: What is your warranty?
A: Our warranty is One Year. Any parts damaged within warranty. We will provide new one for free and supply the solution.

Q: What kind of motor can you supply?
A: Single Phase Motor, Three Phase Motor, NEMA standard motor, Explosion Proof Motor etc.

Q: Do you offer OEM Service?
A: Yes. We offer OEM/ODM service.

Q: What is your lead Time?
A: Usually 10 days. Precise Time depend on Qty.
