NEMA 56C Frame 3/4HP (0.75HP) 24V DC Permanent Magnet Brushed PMDC Motor, 1750RPM / 1800RPM Variable Speed Brush DC Motor for Industrial Conveyor AGV
NEMA 56C Frame 3/4HP (0.75HP) 24V DC Permanent Magnet Brushed PMDC Motor, 1750RPM / 1800RPM Variable Speed Brush DC Motor for Industrial Conveyor AGV
NEMA 56C Frame 3/4HP (0.75HP) 24V DC Permanent Magnet Brushed PMDC Motor, 1750RPM / 1800RPM Variable Speed Brush DC Motor for Industrial Conveyor AGV
NEMA 56C Frame 3/4HP (0.75HP) 24V DC Permanent Magnet Brushed PMDC Motor, 1750RPM / 1800RPM Variable Speed Brush DC Motor for Industrial Conveyor AGV
Specifications
Model Number :
PMDC
Price :
Negotiation
Construction :
Permanent Magnet
Supply Ability :
10000pcs per month
Name :
Permannet DC Motor
Certification :
UL
Payment Terms :
T/T
Speed(RPM) :
1750rpm
Voltage :
24V
MOQ :
10 pcs
Delivery Time :
25 days
Frame :
56C
Power :
3/4HP
Packaging Details :
Cartons/pallet
Brand Name :
BM
Place of Origin :
China
Description

NEMA 56C Frame 3/4HP (0.75HP) 24V DC Permanent Magnet Brushed PMDC Motor, 1750RPM / 1800RPM Variable Speed Brush DC Motor for Industrial Conveyor AGV

1,This NEMA 56C 3/4HP 24V DC Permanent Magnet Brushed Motor is a high-performance PMDC brushed motor built to NEMA MG1 56C standard mounting dimensions.

2,Rated 0.75HP, 24VDC, 1750/1800 full-load RPM, it delivers constant high torque across wide speed range with reliable carbon brush commutation.

3,Adopt high-energy permanent magnet, Class F insulation, IP54 protection, TEFC/TENV enclosure optional. Standard NEMA 56C C-face flange & removable foot base for direct replacement of all 56C frame motors, widely used in battery-powered mobile equipment, conveyors, packaging machinery and light industrial automation.

Power(HP) Speed(RPM) Arm Volt NEMA FRAME ENCL. Curret(Amp.) Torque(In.Ibs) App.Weights(Ibs)
1/4 1750 12 56C TEFC 21.0 9 21
1/4 1750 24 56C TEFC 10.5 9 21
1/3 1750 12 56C TEFC 27.0 12 23
1/3 1750 24 56C TEFC 13.5 12 23
1/2 1750 12 56C TEFC 39.0 18 25
1/2 1750 24 56C TEFC 20.0 18 25
3/4 1750 12 56C TEFC 63.6 27 30
3/4 1750 24 56C TEFC 31.8 27 30
3/4 3600 12 56C TEFC 63.6 13 23
3/4 3600 24 56C TEFC 31.8 13 23
1 1750 12 56C TEFC 80.0 36 32
1 1750 24 56C TEFC 40.0 36 32
1 3600 12 56C TEFC 80.0 17.6 25
1 3600 24 56C TEFC 40.0 17.6 25
1.5 1750 24 56C TEFC 60.0 54.3 43
1.5 3600 24 56C TEFC 60.0 26.4 30

NEMA 56C Frame 3/4HP (0.75HP) 24V DC Permanent Magnet Brushed PMDC Motor, 1750RPM / 1800RPM Variable Speed Brush DC Motor for Industrial Conveyor AGVNEMA 56C Frame 3/4HP (0.75HP) 24V DC Permanent Magnet Brushed PMDC Motor, 1750RPM / 1800RPM Variable Speed Brush DC Motor for Industrial Conveyor AGV

NEMA 56C Frame 3/4HP (0.75HP) 24V DC Permanent Magnet Brushed PMDC Motor, 1750RPM / 1800RPM Variable Speed Brush DC Motor for Industrial Conveyor AGV

NEMA 56C Frame 3/4HP (0.75HP) 24V DC Permanent Magnet Brushed PMDC Motor, 1750RPM / 1800RPM Variable Speed Brush DC Motor for Industrial Conveyor AGV

FAQ
Q: Are you Factory or Trading Company?
A: We are Factory. That has been focusing on motors and accessories for more than 20 years.

Q: What is your warranty?
A: Our warranty is One Year. Any parts damaged within warranty. We will provide new one for free and supply the solution.

Q: What kind of motor can you supply?
A: Single Phase Motor, Three Phase Motor, NEMA standard motor, Explosion Proof Motor etc.

Q: Do you offer OEM Service?
A: Yes. We offer OEM/ODM service.

Q: What is your lead Time?
A: Usually 10 days. Precise Time depend on Qty.
