Specifications
Brand Name :
MTL
Model Number :
MTL5522
Place of Origin :
England
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T,Western Union
Supply Ability :
500pcs/month
Delivery Time :
3 working days
Packaging Details :
original package
Condition :
original brand new
Warranty :
one year
Shipping way :
DHL FedEx express
Application :
Automation Industries, oil, gas, chemical industries
Certificate :
CE ISO TUV
Description
MTL5522 MTL Safety Barriers Isolators Solenoid Alarm Driver
Eaton Crouse-Hinds series MTL5500 solenoid/alarm driver featuring 1 channel digital output, 20-35 Vdc power supply, and comprehensive safety certifications for hazardous locations.
Product Name Eaton Crouse-Hinds series MTL5500 solenoid/alarm driver
Catalog Number MTL5522 - FSM ASSESSED
EAN 3066227675830
Product Dimensions 109.8 mm (L) × 118.8 mm (H) × 15.8 mm (W)
Product Weight 150 g
Global Catalog MTL5522
Product Type Solenoid/alarm driver
Technical Specifications
Type Loop-powered, IIB
Area Classification Hazardous/Classified Locations
Standards IEC, IECEx/ATEX
Hazardous Rating Zone 0
Operating Temperature -20°C to 60°C
Storage Temperature -40°C to 80°C
Humidity 5-95% relative humidity
Signal Type Digital output
Response Time Output within 10% of final value within 100ms
Number of Channels 1
Terminal Capacity Accepts conductors up to 2.5mm² stranded or single-core
Mounting Method T-section 35mm DIN rail
EMC EN61326
Ripple <0.5% of maximum output, peak-to-peak
Safety Integrity Level SIL1 and SIL3 according to IEC61508
Electrical Connection Crimp ferrules
Electrical Characteristics
Power Supply 20-35 Vdc
Current Consumption 125mA at 24V
Current Limit 70mA minimum
Maximum Input Voltage 20-35 Vdc
Minimum Output Voltage 10.7V at 70mA
Maximum Output Voltage 24V from 158Ω
Galvanic Isolation 250V rms between safe-area circuits and power supply
Power Dissipation 1.4W at 24V
Indication Features
  • LED status indication
  • Yellow LED color for status monitoring
